CRL TV20411 U.S. Aluminum 7200 Series Clear Anodized Project-In Top Vent Window for 1" Glazing

CRL TV20411 - U.S. Aluminum Clear Anodized 7200 Series Project-In Top Vent Window for 1" Glazing offers a premium solution for enhancing your building's thermal performance and aesthetic appeal. This thermally broken system is engineered for exceptional insulation, ensuring optimal energy efficiency and comfort within your space. Constructed with durable stainless steel 4-bar hinges and diecast cam locking handles, this window guarantees long-lasting functionality and security. The C-75 AAMA-rated design features reinforced corners with an aluminum corner key, contributing to its strength and stability. With a nominal wall thickness of .062", the window is built to withstand the elements while providing a sleek, modern look. The project-in top vent design facilitates efficient ventilation, making it suitable for various applications. Each unit is constructed for dry glazing with tape on the outside and an E.P.D.M. elastomeric wedge on the inside for 1" glazing (not included). The tubular vent construction, mitered and hydraulically crimped, ensures durability and precision. Please note that shipping is available via common carrier only, and it is recommended to verify shipping costs with CRL Customer Service prior to placing your order. The clear anodized finish enhances its visual appeal while providing resistance to corrosion.

-U.S. Aluminum Clear Anodized 7200 Series Project-In Top Vent Window for 1" Glazing

• Thermally Broken System for Exceptional Thermal Performance
• Stainless Steel 4-Bar Hinges and Diecast Cam Locking Handles
• C-75 AAMA Rated with Reinforced Corners with an Aluminum Corner Key
• .062" Nominal Wall Thickness

Resources

• AAMA Test Report Expiration Statement
• AAMA Test Report Expiration Statement
• Glazing Unit Quote Request Form
• Glazing Unit Quote Request Form
• Institutional Project Case Studies
• Institutional Project Case Studies
• Series 7200 7300 3-Part Spec
• Series 7200 7300 3-Part Spec
• Series 7200 7300 7400 7500 7600 8000 8100 8200 Window Numbering Key
• Series 7200 7300 7400 7500 7600 8000 8100 8200 Window Numbering Key
• Series 7200 7300 Architectural Design Manual
• Series 7200 7300 Architectural Design Manual
• Series 7200 7300 Outswing Casement NFRC Simulations Report 96062.04-116-45
• Series 7200 7300 Outswing Casement NFRC Simulations Report 96062.04-116-45
• Series 7200 7300 Outswing Casement NFRC Simulations Report 96062.04-116-45
• Series 7200 7300 Project In Awning NFRC Simulations Report 96068.03-116-45
• Series 7200 7300 Project In Awning NFRC Simulations Report 96068.03-116-45
• Series 7200 7300 Project Out Awning NFRC Simulations Report 96067.03-116-45
• Series 7200 7300 Project Out Awning NFRC Simulations Report 96067.03-116-45
• Series 7200 7300 Window System Product Information
• Series 7200 7300 Window System Product Information
• Series 7200 7300 Window Systems Installation Instructions
• Series 7200 7300 Window Systems Installation Instructions
• Series 7200 AAMA WDMA CSA 101 I.S.2 A440-08 Report CCLI 10-167
• Series 7200 AAMA WDMA CSA 101 I.S.2 A440-08 Report CCLI 10-167
• Series 7200 ASTM E 90 Sound Transmission Loss Test Report
• Series 7200 ASTM E 90 Sound Transmission Loss Test Report
• Series 7200 Casement Out-Swing Window - AAMA WDMA CSA 101 I.S.2 A440-08 Report CCLI-10-168
• Series 7200 Casement Out-Swing Window - AAMA WDMA CSA 101 I.S.2 A440-08 Report CCLI-10-168
• Series 7200 Fixed Window Glazing Chart
• Series 7200 PI - AAMA Class CW-PG 75-AP 60 X 32 - E0631.01-301-47-R0
• Series 7200 PI - AAMA Class CW-PG 75-AP 60 X 32 - E0631.01-301-47-R0
• Series 7200 PO - AAMA Class CW-PG 75-AP 60 X 32 - E0632.01-301-47-R0
• Series 7200 PO - AAMA Class CW-PG 75-AP 60 X 32 - E0632.01-301-47-R0
• Series 7200 Project In Window Glazing Chart
• Series 7200 Project In Window Glazing Chart
• Series 7200 Project Out Window Glazing Chart
• Series 7200 Project Out Window Glazing Chart
• Series 7200 Project-out Bottom NFRC Simulations Report 85597.01-116-45
• Series 7200 Project-out Bottom NFRC Simulations Report 85597.01-116-45
• Series 7200 Window Quote Request Form
• Series 7200 Window Quote Request Form
• Series 7200 Windows CAD Drawings.dwg
• Series 7200 Windows CAD Drawings.dwg
• Series 7200 Windows CAD Drawings.pdf
• Series 7200 Windows CAD Drawings.pdf
• USAL14 The Storefront Store Catalog
• USAL14 The Storefront Store Catalog
• USAL15 Curtain Walls Catalog
• USAL15 Curtain Walls Catalog
