CRL TV40422 U.S. Aluminum 7400 Series Bronze Anodized Project-In Top Vent Window

CRL TV40422 - U.S. Aluminum Class I Bronze Anodized 7400 Series Project-In Top Vent Window for 1" Glazing combines functionality with durable construction, making it a reliable choice for both commercial and residential applications. This window features a polyamide strut thermal break, ensuring superior energy efficiency, while the reinforced corners, secured with an aluminum corner key, enhance structural integrity. Designed to accommodate various configurations, this window can be utilized as a projected, fixed, or casement option, providing versatility for any project. It meets the stringent AW-95 AAMA rating, ensuring high performance in demanding environments. Constructed with a .125" nominal wall thickness, it is built to withstand the test of time. The operating hardware includes robust stainless steel 4-bar hinges and secure cam locking handles, providing ease of use and enhanced security. For added functionality, optional hardware such as roto operators, limit devices, and access control locks can be integrated seamlessly. The window units are designed for dry glaze installation, featuring tape on the outside and an E.P.D.M. elastomeric wedge on the inside. With optional extrusions available for head and jamb channels, mulling bars, and subsills, the CRL TV40422 offers a comprehensive solution for your glazing needs, ensuring both aesthetic appeal and long-lasting performance.

-U.S. Aluminum Class I Bronze Anodized 7400 Series Project-In Top Vent Window for 1" Glazing

• Polyamide Strut Thermal Break
• Reinforced Corners with an Aluminum Corner Key
• Projected, Fixed, or Casement
• AW-95 AAMA Rated
• .125" Nominal Wall Thickness
