C.R. Laurence ZER000CH Polished Chrome Zero Hinge Set delivers a cutting-edge solution for contemporary shower installations, combining sleek design with advanced functionality. Designed to accommodate 3/8" (10 mm) to 1/2" (12 mm) thick glass, this hinge set features a rise-and-fall action that lifts the glass door by 1/4" (6.35 mm) upon opening. This innovative mechanism allows for a barrier-free experience, eliminating the need for a bottom sweep and reducing friction, which is particularly beneficial for wheelchair accessibility. The Zero Hinge Set is self-centering from 60° and offers an adjustable positive closure of up to +/-15°, ensuring precise door alignment. Versatile installation options enable use in glass-to-wall or glass-to-glass configurations, with the ability to mount on walls or floors. Snap-on covers neatly conceal mounting hardware, maintaining a clean aesthetic. This product can support door weights up to 167 lbs (75.74 kg) and widths of 45 in. (1143 mm), making it suitable for a variety of applications. Note that specific accessory kits for 90° and 135° installations are sold separately. Elevate your architectural design with the C.R. Laurence Zero Hinge Set, where style meets practicality.
Polished Chrome Zero Hinge Set
The CRL Zero Hinge Set offers a sleek, next-generation solution for shower installations, featuring a modern design and advanced technological breakthrough. The Zero Hinge Set is self-centering within +/-60° of the closed position, ensuring precise alignment. It accommodates 3/8"" (10 mm) and 1/2"" (12 mm) glass and utilizes a rise-and-fall mechanism that lifts the glass door by 1/4" (6.35mm) upon opening. This provides the option to eliminate the need for a bottom sweep and reduces friction with the sweep, facilitating barrier-free wheelchair accessibility. The dedicated top and bottom Zero Hinges are position-specific and are not interchangeable. Its versatile technology allows the Zero Hinge Set to suit multiple applications, whether glass-to-wall or glass-to-glass. It can be installed on the wall or floor (acting as a pivoting hinge). The integrated clamp feature for floor installations reduces the need for additional hardware, for 90°, 135°, or 180° applications.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Finish/ Color:: Polished Chrome
Glazing Thickness: 3/8 in. To 1/2 in. (10 mm To 12 mm)
Material: Brass
Maximum Clamping Screw Torque: 60-70 lbf.in (677.9-791 cN.m)
Maximum Door Weight: 167 lbs (75.74 kg)
Maximum Door Width: 45 in. (1143 mm)
Mounting Type: Wall Mount or Glass to Glass When Used with a Second Set
Opening Style: Swing (Side)
Series: Zero Collection
Shipping Limitations: None
Style: Concealed/Premium
