Dortronics WR5276-HD29-E1 3/4in Round Stainless Entry Button, Weather Resistant, Momentary, Double Pole

Dortronics Systems, Inc. WR5276-HD29-E1 3/4in Round Stainless Entry Button or Door Bell is a robust solution designed for exterior applications and challenging environments. Crafted from brushed stainless steel, this heavy-duty, weather-resistant push button switch is perfect for maintaining functionality under harsh conditions. The included neoprene gasket ensures secure mounting, enhancing its durability. This model is rated IP65, making it suitable for wash down applications as it can withstand water projected from nozzles in any direction. An optional bi-color LED ring provides visual indication of switch status, with colors changing based on the polarity of the 24V DC applied. The dual form Z switch contacts allow for isolated normally open and normally closed circuits, enabling simultaneous control of independent systems. With an actuator force of 550 +/-50gF and operational temperatures ranging from -130°F to 158°F, the WR5276-HD29-E1 is designed for resilience. The button supports momentary action with a contact rating of 2A at 24VDC or 125VAC. Custom engraving options are available, making it versatile for various installations. Enhance your access control systems confidently with this reliable and efficient entry button.

3/4in Round Stainless Entry Button or Door Bell, Weather Resistant, Water Proof, Single Gang Stainless Steel Plate, Double Pole, Momentary, Normally Open No

Heavy duty, water proof, push button switch constructed of brushed stainless steel is ideal in exterior applications and for use in harsh operating conditions. A neoprene gasket is included for mounting the switch plate.

Features:

• Suitable for Wash down Applications: The WR5276 series button is rated to a sealing degree of IP65. (Protected against water projected from a nozzle from any direction).
• LED Illuminated Indicator: The optional bi-color LED ring can be utilized to provide visual indication of switch status or may be controlled independently by other devices. The Illuminated LED ring color is red or green depending on the polarity of the 24 volts DC applied to the independent LED ring contacts
• Dual Form Z Switch Contacts: Isolated normally open and normally closed switch contacts allow simultaneous control of independent circuits; such as controlling normally closed lock power while signaling the access control system with a normally open contact.
• Alternate or Momentary: The WR5276 series push button switches are available with momentary or alternate-action switch operation.
• Optional Engraving: Along with standard switch plate sizes, and five standard engraved legends, custom plates and text can be made to specification with quick turnaround.
• WR5276-HD28 – Alternate Action Form Z Non-Illuminated
• WR5276-HD28xLRG – Alternate Action Form Z & Illuminated LED Ring
• WR5276-HD29 – Momentary Action Form Z Non-Illuminated
• WR5276-HD29xLRG – Momentary Action Form Z & Illuminated LED Ring

Specifications:

• Physical Data:
• Actuator Material – Brushed Stainless Steel ¾" Dia.
• Actuator Force – 550 +/-50gF
• Operating Temp – -130F to 1580F, -250C to 700C
• IP Rating – IP65 Waterproof Button
• Electrical:
• Contact Rating - 2A @ 24VDC, 2A @ 125VAC
• LED Ring - Red / Green 24VDC, 120 mA Peak Current, 20 mA Operating Current

Optional Engraving:

• E1 – "PUSH TO EXIT"
• E2 – "PANIC"
• E3 – "EMERGENCY RELEASE"
• E4 – "PUSH TO RELEASE"
• E5 – "EMERGENCY DOOR RELEASE"
• E6 – Custom Engraving
