Elk Products Inc ELK-924 DPDT Relay offers a versatile and efficient solution for general-purpose switching of devices and high current loads. Operating on either 12 or 24 volts DC, this relay module is designed to be triggered by a low current input of just 1.2 mA, making it exceptionally sensitive and ideal for a variety of applications. The double form "C" DPDT contacts provide a robust contact rating of 7A at 30VDC and 10A at 125VAC, ensuring it can handle demanding tasks with ease. The ELK-924 features both positive and negative trigger inputs, providing flexibility in installation. An onboard LED status indicator allows for easy monitoring of relay activity. Included double-sided mounting tape simplifies installation, while its compact size of 1.5" x 2.75" allows it to fit conveniently in standard 2.75" snap tracks. For added convenience, the product is packaged in a reusable poly storage box, and it comes with a lifetime limited warranty, underscoring its durability and reliability. Whether you're a building professional or a knowledgeable homeowner, the ELK-924 is a valuable addition to your security and access control applications.
DPDT Relay 12 Or 24 Volts
The ELK-924 Sensitive Relay module features DPDT (Form "C") dry contacts for general purpose switching of devices or high current loads. It operates on 12 or 24 volts DC and can be triggered with a negative or positive input at an incredible low current of only 1 milliamp. Also available in a 4 pack (ELK-9244) which is packaged as 4 relay modules grouped on a pre-scored break-off circuit board.
Features:
Specifications:
Ship via: Can Ship UPS
Alternate Codes: 104371, 924, ELK-924
Category: Access Control, Access Management, Hardwired
Function: Relay Module
Voltage: 12V DC, 24V DC
