Falcon Lock W511BD HAN 626 Grade 2 Entry/Office Lock

Falcon Lock W511BD HAN 626 Grade 2 Entry / Office Lock offers a robust solution for lower traffic doorways in various environments, including government, retail, and multi-family applications. This Grade 2 cylindrical lock features a Hana knob design with a standard rose, beautifully finished in satin chrome, making it an attractive addition to any door. Designed for versatility, the W511BD is non-handed and can accommodate door thicknesses ranging from 1-3/8" to 1-3/4". With a standard backset of 2-3/4" and an option for 2-3/8", this lock adapts effortlessly to your needs. Constructed with durable materials, the mechanism components are made from brass or cold-formed steel, zinc plated for enhanced rust resistance, while the stainless steel springs ensure longevity. The lock includes a six-chamber cylinder assembly that is easily removable for re-keying and can accept SFIC products from other manufacturers. It is also compatible with Schlage C keyway, providing additional flexibility in key management. The heavy wrought brass or bronze rose is securely installed over a steel insert, ensuring stability. With a UL rating for three-hour fire resistance and compliance with ANSI/BHMA standards, the Falcon W511BD is a reliable choice for any commercial setting.

Grade 2 Entry / Office Lock

Grade 2 Entry/Office Cylindrical Lock, SFIC Prep Less Core, Hana Knob, Standard Rose, Satin Chrome Finish, Non-handed

Falcon is dedicated to providing a solid product at a solid price no matter the application. When an affordable lock is needed for lower traffic doorways in government, retail, industrial or multi-family applications, the W Series lock fits perfectly. With two popular lever and knob styles as well as two popular rose diameters (big and small), Falcon can match most commercial door trim. The Falcon W Series locks feature conventional cylinders and small format interchangeable cores that are compatible with SFIC products from other manufacturers. Our conventional cylinders are available in all Falcon conventional key sections, as well as Schlage C keyway, which we now masterkey across the complete Falcon product line.

Conventional cylinders are available in all Falcon conventional key sections as well as Schlage C Keyway.

• Door Thickness: 1-3/8” to 1-3/4” standard.
• Backset: 2-3/4” standard; 2-3/8” also available.
• Mechanism: Parts constructed of brass or cold-formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
• Attachment: Lock chassis secured to door by two screws which pass through a steel rose insert inside and thread directly into the outer rose-mounting assembly, and two screws that screw into the chassis assembly.
• Handing: Locks are non-handed.
• Cylinder: Pinning in six chambers. Cylinder assemblies removable to re-key. Also available with 6- or 7-pin interchangeable core cylinders. Cylinder housings and plugs machined from solid brass. Springs are stainless steel. Two nickel silver keys furnished standard.
• Competitor Cylinder: The W Series accepts standard 6-pin cylinders available from Falcon, as well as Schlage, Corbin-Russwin, Yale and Sargent.
• Keyways: “G” keyway standard on Falcon standard cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways. Schlage “C” keyway also available on standard cylinders, includes master key. Master keying available on all Falcon and Schlage “C” keyways.
• Trim: Roses are heavy wrought brass or bronze, installed over steel rose inserts which are through-bolted through door. Levers are pressure-cast zinc (solid levers-no-inserts) finished to match mating parts.
• Latches: 1/2” bolt projection made of stainless steel and UL listed for 3-hour door assemblies. Latches have self-adjusting fronts to accommodate beveled or flat doors. 2-3/8” backset with 1” x 2-1/4” latch faces or 2-3/4” backset with 1-1/8” x 2-1/4” latch faces.
• Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard. Consult Options and Accessories section for other available strikes, sizes and configurations.
• Screws: Furnished with combination screws for use in wood or metal doors and frames.
• ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 2.
• UL: 3-hour A label.
