GRI 20RS-12-B Miniature Magnetic Contact Recessed Switch Set, 3/8in, Short Length, Brown

George Risk Industries 20RS-12-B 3/8in Diameter Miniature Magnetic Contact Recessed Switch Set is expertly designed for applications where space is at a premium. This "shortie" switch set, with a length of just .625 inches, fits perfectly in tight areas, allowing for effective security without compromising aesthetics. By utilizing a 3/8" diameter, press-to-fit design, this switch provides a clean installation that minimizes visibility, ideal for thin-framed doors and windows. The 20RS-12-B features a 1/2-inch wide gap in a closed loop configuration, ensuring reliable operation and seamless integration into your security systems. With a standard lead length of 12 inches or an option for terminal blocks, it offers flexibility for various installation scenarios. Backed by a lifetime warranty and UL/ULC approval, this switch set guarantees long-lasting performance and peace of mind. Additionally, customization options such as built-in resistors and diodes are available upon request. Available in both standard and extra wide gaps, the 20RS series provides a practical solution for challenging window security issues, making it a valuable addition to any installer’s toolkit. Ensure your property is secured discreetly with the GRI 20RS-12-B.

3/8in Diameter Miniature Magnetic Contact Recessed (Flush Mount) Switch Set, Short Length (.625 in), 1/2in Wide Gap, Press in to Fit, Closed Loop (N/O), Terminals, Brown

The G.R.I. recessed "shortie" switch set is designed for applications where a 3/8" press to fit set is needed but space limitations will not allow for a full length set to be installed. With the 5/8" 20RS-12, or the .930" 20RS-T, the installer is able to protect openings that otherwise would have to be secured with more visible surface mount configurations. Available in regular and extra wide gaps, the 20RS series provides an easy answer to the difficult, high dollar window problems every installer encounters.

Features:

• Lifetime Warranty
• UL and ULC Approved
• Available in Open Loop, Closed Loop and SPDT
• 3/8" Diameter, Press To Fit
• Standard Lead Length 12" or Terminal Block
• Longer Leads, Zip Cord or Jacketed Cable on Request
• Ideal for Thin Framed Doors & Windows
• Built-in Resistors & Diodes Available on Request
• Switches or Magnets Available Separately
• Standard Gap 3/4"+
• Extra Wide Gap 1"+

Resources

• Cut Sheet
