GRI DS-01-T-B Short Roller Ball Contact Switch, 360 Access, Screw Terminals, Closed Loop, Brown

George Risk Industries DS-01-T-B Short Roller Ball Contact Switch with Screw Down Flange is designed to meet the diverse needs of today’s installation professionals. This innovative switch combines features that make it a top choice for various applications. Its unique single mounting configuration simplifies installation, eliminating the necessity for multiple stock variations for horizontal and vertical mounting. The GRI Short Roller Ball is adaptable enough to replace both standard plunger switches and wheel-type switches, enhancing its versatility. With a flanged collar, it ensures positive and reliable retention, making it an essential component for secure access control systems. This switch is UL and ULC approved, offering peace of mind when it comes to safety and compliance. It is available in a closed loop configuration and features a total travel of .200 inches, with a pre-travel of .080 ± .030 inches. Standard 12-inch leads come included, and longer leads, zip cords, or jacketed cables can be requested for tailored installations. With a lifetime warranty, built-in end-of-line resistors and diodes available upon request, and all necessary hardware included, the GRI DS-01-T-B Short Roller Ball Contact Switch is an excellent choice for reliable performance in security and access control applications.

Short Roller Ball Contact Switch with Screw Down Flange, Contact with 360 Degree of Ball Access, Screw Terminals, Closed Loop (N/O), Brown

The new GRI Short Roller Ball is a unique combination of many Features most requested by today's top install technicians. The single mounting configuration also eliminates the need for multiple stock variations like those required for horizontal and vertical mounting. The GRI Short Roller Ball is so versatile it can be used in place of a regular plunger switch or wheel type switch. The flanged collar insures positive and reliable retention.

Features:

• Lifetime Warranty
• Colors: White or Brown
• UL and ULC Approved
• Available in Closed Loop and SPDT
• Total Travel - .200 Pre Travel - .080 ± .030
• Standard 12" Leads
• Longer Leads, Zip Cord or Jacketed Cable on Request
• Terminal Block Available
• Terminal Switch Indicated by "T" Designation
• Built-in E.O.L. Resistors and Diodes Available on Request
• Hardware and Spacers Included, also Available Separately

Resources

• Cut Sheet
