Hager 3495 26D WTN SFIC Grade 1 Intruder Classroom Lock offers robust security and superior design for commercial applications. This Grade 1 cylindrical lock is engineered to endure heavy use and resist impact, making it ideal for high-traffic environments. The lock features a SFIC prep less core design, allowing for easy rekeying, while the Withnell lever adds a touch of elegance with its straight return style. With a 3-17/32" diameter rose and a satin chrome finish, the Hager 3495 combines durability with aesthetic appeal. It accommodates door thicknesses ranging from 1-3/8" to 2", ensuring compatibility with a variety of commercial door setups. Certified under ANSI A156.2 and A117.1 standards, this lock promotes accessibility and meets ADA compliance requirements. The lock is equipped with a dead latch (guarded) for enhanced security and has a bolt projection of 1/2". It comes with a lifetime warranty, reflecting Hager's confidence in its quality and performance. Additionally, it boasts a fire rating of 3 hours, making it a reliable choice for safety-conscious facilities. Trust the Hager 3495 for your classroom intruder security needs, where function meets style.
Grade 1 Classroom Security Cylindrical Lock, SFIC Prep Less Core, Withnell Lever, 3-17/32" Diameter Rose, Satin Chrome Finish, Non-Handed
Hager 3400 Series Grade 1 Lock is designed and engineered to withstand the most abusive environments. We've categorized it 'extra heavy duty' and you can rest assured that it has been tested against heavy use, impact, strength, resistance, and abuse. We're so confident in our 3400 Series lock, it's backed by a lifetime warranty. The exceptional quality of our 3400 Series lock has made it incredibly successful in application after application across the country and around the globe.
Attributes
Manufacturer surcharge: $ 23.78
Accessible: Yes
Ada Compliance: Yes
Ansi: A156.2, A117.1, A250.13
Ansi Function: F110 - Classroom Intruder
Baa Qualified: No
Bolt Projection: 1/2" Latch
Bore Hole Diameter: 2-1/8"
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: Taiwan
Cylinder Type: SFIC Prep Less Core
Door Thickness: 1-3/8" - 2"
Dust Box: None
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: Yes
Fire Rating: 3 Hours {A}
Function: 95-Classroom Security
Function Family: Classroom
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Latch Bore Diameter: 1"
Leverknob Design: WTN - Withnell Lever
Leverknob Design Family: Straight Return Lever
Limited Warranty: Lifetime
Origin: Taiwan
Pack Qty: 1
Pins: 6
Restrictions: None
Rose Escutcheon Dimensions Inside: 3-17/32" Diameter Rose
Roseescutcheon Design: 3-17/32" Rose Diameter
Screws: Combination
Series: 3400 Series Grade 1 Cylindrical Locks
Std Keyway: Less Core
Std Latch Backset Dim: 2-3/4"
Std Latch Number: 3932
Std Latch Type: Dead Latch (Guarded)
Std Strike Height: 4-7/8"
Std Strike Number: 3935
Std Strike Type: ASA
Std Strike Width: 1-1/4"
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL 10C, UL 10B
Unit of Measure: Each
