Hettich 9285006 105 Soft Close 3/4" Overlay Full Clip Drawer Slide

HETTICH 9285006 105 Soft Close 3/4" OL FF CLIP DWL is designed for those who appreciate quality and functionality in their cabinetry. This hinge features a 105° opening angle, allowing doors to swing open wide for easy access. With a full wrap mounting plate tailored for 3/4" face frames, installation is straightforward and secure. The two-piece design incorporates an integrated Silent System, ensuring that doors close gently and quietly, enhancing the overall user experience. Its sleek nickel finish not only adds an elegant touch but also ensures durability. Adaptability is a key feature of this hinge, boasting 3-way independent cam adjustability. You can easily fine-tune the depth (up to +2.6mm), side (±1.5mm), and height (±1.4mm) to achieve the perfect alignment with your cabinetry. The 11mm cup depth and a boring distance of 3mm make it versatile for a variety of applications, while the specified door gap of 13/64" ensures a seamless fit. This hinge meets and exceeds the minimum requirements of the ANSI/BHMA A156.9 standard, assuring you of its quality and reliability. Upgrade your projects with the HETTICH 9285006 for a professional finish that stands the test of time.

105 Soft Close 3/4" OL FF CLIP DWL

• Nickel finish
• 105° opening angle
• 3-way independent cam adjustability
• - Height adjustment +/- 1.4mm
• - Depth adjustment +2.6mm
• Full wrap mounting plate for 3/4" frame
• Meets and exceeds the minimum requirements of ANSI/BHMA A156.9 standard
• 2 piece hinge with integrated Silent System
• Boring distance = 3mm
• 11mm cup depth
• - Side adjustment +/- 1.5mm
• Door gap 13/64"
