Ives 9264F-12-8 US32D Offset Long Ladder Pull, 1" Dia, 12" L, 8" CTC, Satin Stainless Steel

Ives 9264F-12-8 US32D Offset Long Ladder Pull with Flat Tips combines functionality and style in a robust design. This 1-inch diameter, 12-inch long pull features an 8-inch center-to-center (CTC) post spacing, ideal for enhancing both residential and commercial spaces. Crafted from 316 stainless steel, it exceeds industry standards for corrosion resistance, making it an excellent choice for exterior applications. The flat tips of this offset long pull add a modern touch, seamlessly coordinating with various contemporary door hardware styles. Ives offers a range of finishes, including the sleek satin stainless steel (630/US32D), ensuring you find the perfect match for your décor. Easy to install, the heavy-duty mounting hardware is designed for door thicknesses of 1 ½" to 1 ¾", with optional packages available for thicker doors. With an emphasis on durability and aesthetic appeal, the Ives 9264F-12-8 is not just a functional accessory; it's a statement piece that elevates your door's entrance. Whether you're outfitting a new build or upgrading existing hardware, this long ladder pull is a reliable choice that stands the test of time while maintaining a fresh, modern look. Embrace the combination of strength and elegance with Ives.

Offset Long Ladder Pull with Flat Tips, 1in Diameter, 12in Length, 8in CTC Post, 630/US32D Satin Stainless Steel

Ives long door pulls are offered in offset and straight models, a variety of lengths and center-to-center mounting spacing. In addition, Ives offers a wide selection of finishes, round and flat tip options and mounting hardware to meet any application needs. Offered in 316 stainless steel, the long pulls exceed industry standards for corrosion resistance in exterior applications. Ives long pulls coordinate seamlessly with other contemporary styles and finishes of door hardware for a complete, secure and attractive door solution.

Specifications:

• Offset long door pull, flat tips
• If not specified, standard center to center length for pulls 36" or longer is 16" less than total pull length (8" from each end of the pull); Center to center length must be specified for lengths less than 36". Ex. 72" Long pull has a 56" center to center.
• If the center to center length is less than half the total pull length
• Specify PR when ordering a set of push bars for back to back mounting
• For one back to back machined push bar, specify Nsgl or Psgl (glass doors)
• Additional mounting post required for lengths greater than 96"; Mid posts are optional for other lengths (specify mid post location when ordering)
• Recommend the length of the ladder pull should not exceed 4" less than the door height.
• Available Sizes:
• 1 1⁄4" Diameter tubular bar
• Round tip is standard
• Optional flat Tip (F) is available; specify F after model number when ordering
• Available in whole 1" increments from 12" to 96"
• Material Substrate:
• Made from brass or stainless steel (316 Series)
• 316 Series Stainless Steel standard, exceeding industry standards for corrosion resistance
• Recommended for external applications
• Mounting Hardware:
• Heavy duty mounting hardware exceeds industry standards
• 3⁄8-16 mounting hardware
• Specify door thickness: Standard mounting hardware for door thickness of 1 1⁄2" to 1 3⁄4" unless otherwise specified. Optional package available for 2" and 2 1⁄4" thick doors
• Comes standard with through bolt screws and decorative washers
• Optional mounting hardware available (see general information section for details) A, I, L, N, O, P, Q, X
• Mounting hardware for other door thicknesses are available as engineering special
• Certifications: Meets ANSI/BHMA 156.06

Standard Lengths:

Finishes:

• 605/US3 - Bright Brass
• 606/US4 - Satin Brass
• 613/US10B - Oil Rubbed Bronze
• 619/US15 - Satin Nickel
• 629-316/32-316 - Bright Stainless
• 630-316/32D-316 - Satin Stainless
• 630-AM/US32D-AM - Satin Stainless Antimicrobial
• 631/BLK - Matte Black
• 643e/716 - Aged Bronze
• 695/SP313/US10BE - Dark Bronze Powder Coat

Features

• 316 Series Stainless Steel standard, exceeding industry standards for corrosion resistance
• Comes standard with through bolt screws and decorative washers
• Optional mounting hardware available (see general information section for details) A, I, L, N, O, P, Q, X
• For one back to back machined push bar, specify Nsgl or Psgl (glass doors)
• 3⁄8-16 mounting hardware
• 1 1⁄4" Diameter tubular bar
• Additional mounting post required for lengths greater than 96"; Mid posts are optional for other lengths (specify mid post location when ordering)
• Specify door thickness: Standard mounting hardware for door thickness of 1 1⁄2" to 1 3⁄4" unless otherwise specified. Optional package available for 2" and 2 1⁄4" thick doors
• Round tip is standard
• Recommended for external applications
• Mounting Hardware:
• Heavy duty mounting hardware exceeds industry standards
• Available in whole 1" increments from 12" to 96"
• Recommend the length of the ladder pull should not exceed 4" less than the door height.
• Material Substrate:
• If the center to center length is less than half the total pull length
• If not specified, standard center to center length for pulls 36" or longer is 16" less than total pull length (8" from each end of the pull); Center to center length must be specified for lengths less than 36". Ex. 72" Long pull has a 56" center to center.
• Available Sizes:
• Made from brass or stainless steel (316 Series)
• Certifications: Meets ANSI/BHMA 156.06
• Optional flat Tip (F) is available; specify F after model number when ordering
• Offset long door pull, flat tips
• Mounting hardware for other door thicknesses are available as engineering special
• Specify PR when ordering a set of push bars for back to back mounting
