LCN 1461-HEDA-GLBLK-LH Surface Mount Medium Duty Cast Iron Closer, ADA Adjustable, Left Hand, Gloss Black

LCN Closers 1461-HEDA-GLBLK-LH Surface Mount Medium Duty Cast Iron Closer offers reliable performance and versatility for commercial and institutional settings. Designed to meet ANSI/BHMA A156.4 grade 1 and ADA requirements, this closer is an excellent choice for self-closing doors without hold-open mechanisms. With its durable cast iron body and slim line plastic cover finished in a striking gloss black powder coat, it not only performs well but also enhances the aesthetics of any door system. This universal closer features adjustable spring sizes from 1 to 6, allowing for customized performance based on specific door needs. The patented LCN green dial simplifies spring power adjustments, ensuring quick and accurate setup. Its heat-treated steel pinion journal and all-weather fluid enhance longevity and functionality, especially in challenging climates. Installation is made effortless with peel-n-stick templates, providing a precise mounting hole pattern. Backed by a 30-year limited warranty, the LCN 1461-HEDA-GLBLK-LH is UL and cUL listed, ensuring compliance with rigorous safety standards. Whether mounted on the hinge, top jamb, or parallel arm, this closer delivers consistent reliability, making it ideal for high-traffic areas where durability and performance are paramount. Upgrade your door hardware with this dependable solution today.

Surface Mount Medium Duty Cast Iron Closer, Slim Line Plastic Cover, ADA Adjustable Size 1-6, Grade 1, Left Hand, 693/GLBLK Gloss Black Powder Coat

The 1460 series is a universal medium-duty closer designed for maximum versatility in commercial and institutional applications, meeting ANSI/BHMA A156.4 grade 1 and ADA reduced opening force requirements. It installs quickly, accurately and offers a variety of options. It is cUL and UL listed for self-closing doors without hold-open and boasts a 30-year limited warranty. Features include a slim line plastic cover, with optional plated finish on the cover, the arm and the fasteners. LCN peel-n-stick templates ensure quick and accurate installation, and the patented LCN green dial takes the guesswork out of spring power adjustments.

Features:

• Heat-treated steel pinion journal
• All-weather fluid
• LCN patented green dial spring power indicator
• 30-year warranty
• Universal non-handed
• Peel-n-stick template and standard slim line plastic cover
• Adjustable spring sizes 1-6

Specifications:

• Certifications: Grade 1 - ANSI A156.4, UL 10C, ADA, 100 hour salt spray, meets BAA - buy American Act
• Body construction:
• Cast iron body
• Full complement bearing
• 1-1/4" diameter piston
• 3⁄4" diameter single heat treated pinion journal
• Fluid: All weather
• Templating: Peel-n-stick templates - 1" x 7-1⁄2" mounting hole pattern
• Size: Adjustable spring size 1-6 (includes patented green dial)
• Cover: Slim line plastic, standard, full plastic and metal designer series, optional
• Fasteners: Self reaming and tapping screws (SRT)
• Mounting: Hinge (pull side), top jamb (push side), parallel arm (push side)

Optional Arms:

• 1460-3077: Regular Arm (REGARM)
• Non-handed
• Mounts hinge side or top jamb
• P1460 closer includes PA shoe, 1460-62PA required for parallel arm mounting
• 1460-3077L: Long Arm (LONG)
• Non-handed
• Includes long rod and shoe, 1460-79LR for top jamb mount with deep reveals
• Optional
• 1460-3077HD: Heavy Duty Arm (HD)
• Non-handed
• Mounts hinge side, top jamb or parallel arm
• Optional
• 1460-3077HDL: Heavy Duty Long Arm (HDLONG)
• Non-handed
• Includes long rod and shoe, 1460-79LR for top jamb mounts with deep reveals
• Optional
• 1460-3049: Hold Open Arm (H)
• Non-handed
• Mounts hinge side, top jamb or parallel arm (62PA required)
• Hold-open adjustable at shoe
• Optional
• 1460-3049L: Hold Open Long Arm (HLONG)
• Non-handed
• Includes long head and tube, 1460- 3048L for top jamb mount with deep reveals
• Optional
• 1460-3077EDA: Extra Duty Arm (EDA)
• Non-handed
• Features solid forged steel main and forearm for potentially abusive installations
• Optional 1460-3077EDA/62G for blade stop clearance
• 1460-3077EDA/62G: Extra Duty Arm with 62G Thick Hub Shoe (EDAW62G)
• Non-handed
• Features solid forged steel main and forearm for potentially abusive installations
• 1460-3049EDA: Hold Open Extra Duty Arm (HEDA)
• Handed
• Provides hold open function adjustable at shoe
• Optional
• 1460-3077CNS: Cush-n-Stop Arm (CUSH)
• Non-handed
• Features solid forged steel main arm and forearm with stop in soffit shoe
• Optional
• 1460-3049CNS: Hold Cush-n-Stop Arm (HCUSH)
• Non-handed
• Provides hold open function with templated stop/hold open points
• Handle controls hold open function
• Optional
• 1460-3077SCNS: Spring Cush-n-Stop Arm (SCUSH)
• Non-handed
• For abusive applications features solid forged steel main arm and forearm with spring loaded stop in the soffit shoe
• Optional
• 1460-3049SHCNS: Spring Hold Open Cush-n-Stop Arm (SHCUSH)
• Non-handed
• For abusive applications features solid forged steel main arm and forearm with spring loaded stop in the soffit shoe
• Handle controls hold open function
• Optional

Finishes:

• 689 - Aluminum
• 690 - Statuary bronze
• 691 - Light bronze
• 693 - Black
• 695 - Dark bronze
• 696 - Brass
