LCN 4040XP-78H 689 H Head Tube Aluminum Assembly

LCN 4040XP-78H 689 H Head and Tube AL is engineered for exceptional durability and flexibility, making it an ideal choice for institutional and high-traffic environments. This heavy-duty closer is designed to withstand the rigors of constant use and abuse, ensuring reliable performance in demanding applications. With a robust construction that includes the strongest pinion ever at a 3/4" journal diameter and a 5/8" wide bearing, the 4040XP sets a new benchmark for longevity and reliability. Its innovative V-shield™ seal extends service life by 20%, while the non-handed design simplifies installation on either right or left swinging doors. This closer also features LCN® Fast™ Power Adjust technology, allowing for quick and precise adjustments. It is tested and certified under ANSI Standard A156.4, grade one, ensuring that it meets stringent safety and performance criteria. Suitable for both interior and exterior doors, the 4040XP can be mounted in multiple configurations, including hinge side, top jamb, or parallel arm. Additionally, it is UL and cUL listed for self-closing doors without hold-open and comes with a 30-year limited warranty, underscoring its value and reliability. Available in a matte silver finish, this closer blends functionality with style, making it a smart choice for any commercial setting.

H Head and Tube AL

H Head and Tube, Aluminum Finish

LCN's most durable and flexible heavy duty closer designed for institutional and other demanding high traffic applications.

Durable, non-handed, heavy duty closer designed for the most demanding, high-use and abuse applications.

The LCN 4040XP sets a new standard for reliability, longevity and value with a beefier design and extraordinary performance testing that goes far beyond industry requirements. LCN built the 4040XP from the inside out, combining tougher, bolder construction with proven LCN technology. The result is a closer that’s stronger, smarter and delivers remarkable value in a variety of applications.

• 44% increased bearing load capacity
• Strongest pinion ever, at 3/4" journal diameter
• Widest bearing ever, at 5/8"
• Stronger pinion teeth
• New V-shield™ seal with 20% longer life
• XP = eXtra Protection in real world applications
• Cast Iron
• Forged Steel Arm
• Double Heat Treated Steel Pinion
• All Weather Fluid
• Non-Handed
• LCN® Fast™ Power Adjust
• Fast & Accurate Installation
• UL & cUL Listed
• Tested and certified under ANSI Standard A156.4, grade one
• Non-sized cylinder is adjustable for interior doors to 5’0” and exterior doors to 4'0"
• Closer can mount hinge side, top jamb, or parallel arm (with PA bracket) on either right or left swinging doors
• Closers to meet ADA requirements
• Standard or optional custom powder coat finish
• Optional plated finish on metal cover, arm and fasteners
• Optional SRI primer for installations in corrosive conditions is available with powder coat only
• UL and cUL listed for self-closing doors without hold-open
• 4040XP can be used with all 4040 accessories
