Lifesafety Power Inc FPO250-E4 E4 Enclosure with 250W Power Supply is a robust offline switch mode power supply battery charger tailored for the lifesafety industry. This versatile unit delivers two selectable power outputs of either 12 or 24 VDC, ensuring compatibility with various systems. Enclosed in a durable painted steel casing, it features a locking mechanism and a tamper switch for enhanced security. The FPO250-E4 is designed with practicality in mind, offering one continuous output for system use and a second programmable output that can be set for fail-safe or fail-secure operation when triggered by a fire alarm disconnect. Its integrated microprocessor supports dual-rate charging, effectively restoring battery sets from 4 to 80 amp hours. Additionally, it boasts comprehensive fault detection and reporting capabilities, including optional earth ground and battery presence monitoring. With a maximum input power of 282 Watts and an efficiency rating of 88%, this power supply ensures reliable performance. The fire alarm interface facilitates smooth egress lock control, while the modular design allows for multiple outputs for system power, direct lock control, and accessory power distribution. The Lifesafety Power FPO250-E4 is an essential component for any high-security installation, providing peace of mind and superior functionality.

E4 Enclosure with 250W Power Supply, Single Voltage

The Flexpower FPO250-E4 is an offline switch mode power supply battery charger specifically designed for the lifesafety industry. Capable of providing two power outputs, user selectable for 12 or 24 VDC, the unit is configured in a painted, steel, locking enclosure with tamper switch and integral battery space. One output provides continuous output power for system use, the second is programmable for either fail-safe or fail-secure operation, activated when the fire alarm disconnect is initiated. Complete fault detection and reporting, with programmable fault delays, is provided along with datalogging capability of fault occurrence, battery usage time and current power supply status.

Features:

• Fully modular power management system
• Multiple outputs for system power, direct lock control and accessory power distribution modules
• Fire alarm interface for egress lock control (FAI)
• Configurable fail-safe / fail-secure modes of operation
• Comprehensive fault detection and reporting including optional earth ground and battery presence
• AC and system fault output relays can be delayed via PowerCom
• Microprocessor dual rate charging restores battery sets from 4 to 80 amp hours

Specifications:

• Input Voltage: 120/230 VAC
• Input Power (max): 282 Watts
• Output Voltage: 12 or 24 VDC
• Output Current: 20 or 10 Amps
• Battery Charge Capacity: 80Ah
• Efficiency: 88%
• Output Ripple: 120 mVp-p
• Line Regulation: 0.1 ±%
• Load Regulation: 2 ±%
• BTU Rating: 109 BTU/Hr
• Continuous Power Outputs: 1
• Switched Power Outputs: 1
• Fire Alarm Interface: Yes
