Lifesafety Power FPO75-B100C8D8E2-3SL1 Salto DV E2 75W Power Supply for 6 Door Keyless Mobile Access, 8 Outputs

Lifesafety Power Inc FPO75-B100C8D8E2-3SL1 Power Supply System is an all-in-one solution designed for 4-10 door Salto access systems. With a robust 75W capacity and dual voltage options (12V and 24V), this power supply offers maximum flexibility and efficiency for security system designers. The integrated keyless and mobile access features streamline operations, while the system supports eight lock controls and eight auxiliary outputs, each fused at 3A. This power supply boasts a labor-saving design with pre-wired sections, pre-punched knockouts, and mounting brackets for three SALTO modules, ensuring a hassle-free installation process. Its built-in 1A charger for sealed lead acid or gel batteries guarantees reliable battery backup, seamlessly switching to standby mode during AC failures without any delay. Key specifications include a 120/230 VAC input with overload protection and a 2A maximum output for both 12V and 24V DC. The enclosure, measuring 20.00H x 16.00W x 4.50D inches, is compact yet spacious enough to accommodate a battery set and provides an organized wire management room. With visual indicators for system and AC faults, Lifesafety Power Inc's FPO75-B100C8D8E2-3SL1 ensures continuous monitoring and peace of mind for any security setup.

Power Supply System, 6 Door Integrated Keyless and Mobile Access, Salto DV E2 75W, 2A/12V and 2A/24V 8 Lock and 8 Aux Outputs, Three Salto Plates

All-in-one power solutions for 4-10 door Salto systems using CU42E0, CU4200, or CU4EB8 controllers. Single, dual voltage/Networked. Salto unified power systems offers maximum flexibility, functionality and savings to access system designers. Salto Unified enclosures are engineered to house Flexpower boards in one compact, secure system.

Features:

• FPO offline power supply:
• 120 or 230 VAC input
• 12 and 24 VDC outputs
• On board Fire Alarm Interface
• Continuous and resettable DC
• Distributed output module:
• Eight auxiliary - fused at 3A each
• Eight lock control - fused at 3A each
• Expansion options:
• Increased power, multiple voltages
• Additional distribution outputs
• Network monitoring and reporting
• Labor saving design:
• Pre-wired power section
• Pre-punched knockouts
• Preinstalled brackets hold three SALTO modules
• Flexible backplate mounting locations
• Access panels mount on threaded studs - no drilling required
• Additional benefits:
• Wire management room
• 4.5" enclosure depth fits battery set
• Tamper switch, lock, dual key set standard
• Mounting hardware for access boards included

Specifications:

• Input Power:
• Input 120/230 VAC 50/60 Hz | 83 Watts (0.69A)
• Overload and short circuit protection
• Over temperature protection
• Polarized AC power supply disconnect
• Output Power:
• 2A@12V and 2A@24V DC, 75W maximum combined output power
• Outputs: Continuous (DC1) Resettable (DC2)
• 8 controlled outputs, fused at 3A each
• 8 auxiliary outputs, fused at 3A each
• 120 mV output voltage ripple
• System Efficiency: 83% | System BTU Rating: 33 BTU/Hr
• Battery Charging:
• Independent built-in 1A charger for sealed lead acid or gel type batteries
• Microprocessor dual rate charging of 24 V battery sets
• Automatic switchover to standby battery when AC fails
• Zero delay when switching over to battery backup
• Supervision: AC Fail (form "C" contacts) System fail (form "C" contacts) may be triggered by low/no battery, short to earth ground and power supply failure
• Visual Indicators:
• AC input, DC1 and DC2 output
• System fault | AC fault | Short to earth ground | Reverse battery polarity
• Fire alarm input activated
• B100: DC input/output and fault
• C8: DC output and fault
• D8: DC output
• Enclosure Dimensions: Size: 20.00H x 16.00W x 4.50D in. (50.00 x 40.00 x 11.50 cm) | Weight: 18 lbs
