Marks Hardware 145KL/10B Marks C Keyway Single Cylinder Gate Lock, 6 Pin, 2-3/4in Backset, Dark Bronze

Marks Hardware 145KL/10B KIT is a robust gate lock that combines security and convenience with its single cylinder x lever design. Crafted for durability, this lock features a Marks C keyway and a 6-pin cylinder, ensuring a high level of security while providing ease of access. The 2-3/4 inch backset allows for compatibility with a wide range of door types, making it suitable for both residential and commercial applications. With a Grade 1 deadlatch rated under ANSI 156.5, this lock is engineered to withstand forced entry attempts. Its steel shutter system effectively conceals mounting screws when locked, enhancing security further. The tapered cylinder collars are designed to resist break-in attempts, showcasing Marks Hardware's attention to detail in security design. Installation is streamlined with unitized assemblies for a 2-1/8 inch bore, accommodating door thicknesses of 1-3/4 inches. The lock includes a #1136 strike for optimal performance. Finished in a sophisticated dark bronze (613/US10B), it complements various architectural styles while providing a professional aesthetic. Whether you’re securing a gate or enhancing the security of your property, the Marks Hardware 145KL/10B KIT delivers peace of mind with its reliable performance and premium features.

KIT - Gate Lock Single Cylinder X Lever, Marks C Keyway, 6 Pin, 2-3/4in Backset, 613/US10B Dark Bronze

Marks USA manufactures a versatile series of grade 1 deadlatches and deadbolts which install easily and accept most other manufactures conventional, high security and IC core cylinders.

Features:

• Deadbolt: ANSI 156.5 grade 1 (UL fire ratings not applicable)
• Deadlatch: ANSI 156.5 grade 1, UL fire rated 3 hours
• Accepts Medeco, Kaba, Multilock, ASSA and other high security cylinders
• IC core models for "Best" size cores
• Accepts most manufactures conventional cylinders
• Unitized assemblies for 2-1/8" bore
• Tapered cylinder collars prevent (break in attempts by) wrenching
• Steel shutter system eliminates access to mounting screws when door is locked.
• Series 1 cylindrical cartridge
• Unitized assemblies for 2-1/8" bore

Specifications:

• Latch: Grade 1, 9/16" throw, 2-3/4" backset
• Strike: #1136, 2-3/4" strike
• Door Thickness: 1-3/4"; For 1-3/8" doors use spacer rings K1442/32D
• Cylinder: Marks "C" keyway, 6 pin w/ 2 keys
• Latch front: 1-1/8" x 2-1/4"

Functions:

• K: Cylinder x turnpiece
• L: Communicating single cylinder
• M: Double cylinder
• KL: Cylinder x lever
• X: Turnpiece x blank plate
• KK: Cylinder x knob

Finishes:

• 3 - Bright brass
• 32D - Stainless steel
• 10B - Dark bronze
• 26D - Satin chrome
