Outside locked by pushing turn-button inside. Key outside opens lock. Rotating inside lever releases button and outside lever. By pushing and turning inside button, outside lever remains locked.
Attributes
Manufacturer surcharge: $ 0.0
Accessible: Yes
Ada Compliance: Yes
Alternate Codes: 175RAB/26D-F19, 175RAB26DF19, MAR175RAB/ 26D-F19
Ansi: A156.2
Ansi Function: F109
Baa Qualified: Yes
Backset: 2-3/4"
Bolt Projection: 1/2"
Burglar Rated: No
Category: Commercial Locks, Cylindrical Levers, Lock Sets
Certifications: A156.2, ANSI, UL Listed 3 Hour
Commercial Residential: Commercial
Country of Origin: Usa
Country of origin: USA
Cylinder Type: Interchangeable , Less Core
Door Application: Lock Sets
Door Thickness: 1-5/8"-1-7/8"
Faceplate Height: 2-1/4"
Faceplate Width: 1-1/8"
Finish: 626/US26D
Finish Code: 626
Finish Color: Brushed Chrome, Satin Chrome
Finish Description: Satin Chrome
Finish Family: Matte Silver
Fire Rated: Yes
Fire Rating: 120 min
Function: Entrance
Grade: Grade 2
Handing: Non-Handed
Installation: Commercial
Latch Throw: 1/2"
Latchbolt Type: Deadlatch
Lever Design: American
Lever/ Knob Cylinder Prep: Schlage 6 pin IC core
Leverknob Design: 175 - American Lever
Limited Warranty: Lifetime
Lock Face Size: 1-1/8" x 2-1/4"
Manufacturer: Marks USA
Origin: USA
Pack Qty: 1
Pins: 6
Restrictions: None
Rose/ Escutcheon: 3-1/4" Diameter, Spring Loaded
Roseescutcheon Design: 3-1/4" Rose Diameter
Screws: Combination
Series: 75 Line
Std Latch Backset Dim: 2-3/4"
Std Latch Number: 1134
Std Strike Number: 1145
Std Strike Type: ASA Strike
Subtype: Cylindrical Lock
Type: LOCK SETS
Ul Listing: UL 10C
Unit of Measure: Each
