Key both levers. Locks or unlocks either lever independent of the other.
Attributes
Accessible: Yes
Ada Compliance: Yes
Alternate Codes: 110207, 113008, 195DC/26D, 195DC26D
Ansi: A156.2
Ansi Function: F80
Baa Qualified: Yes
Backset: 2-3/4"
Bolt Projection: 9/16"
Burglar Rated: No
Category: Commercial Locks, Cylindrical Levers, Lock Sets
Certifications: A156.2, ANSI, UL Listed 3 Hour
Commercial Residential: Commercial
Country of Origin: Usa
Country of origin: USA
Cylinder Included: Yes
Cylinder Type: 6-Pin Cylinder
Door Application: Lock Sets
Door Bore Size: 2-1/8"
Door Thickness: 1-5/8"-1-7/8"
Door Thickness Max: 1-7/8"
Door Thickness Min: 1-5/8"
Finish: 626/US26D
Finish Code: 626
Finish Color: Satin Chrome
Finish Description: Satin Chrome
Finish Family: Matte Silver
Fire Rated: Yes
Fire Rating: 120 min
Function: Communicating
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Keying: Keyed Different
Keys: Cut
Keyway: Marks C
Knob/ Lever Design: 195
Knob/ Lever Style: Lever
Latch Bolt Face Type: Square Corner
Latch Bolt Faceplate Size: 2-1/4" x 1-1/8"
Latch Bolt Throw: 1/2"
Latch Bolt Type: Deadlatch
Latch Throw: 9/16"
Latchbolt Type: Deadlatch
Lever Design: American
Leverknob Design: 195 - American Lever
Limited Warranty: Lifetime
Lock Category: Cylindrical Lock
Lock Face Size: 1-1/8" x 2-1/4"
Manufacturer: Marks USA
Of Keys: 2
Origin: USA
Pack Qty: 1
Pins: 6
Restricted Keyway: No
Restrictions: None
Rose/ Escutcheon: 3-7/16" Diameter, Spring Loaded
Rose/ Escutcheon Size: 2-9/16"
Rose/ Escutcheon Style: Rose
Roseescutcheon Design: 3-7/16" Rose Diameter
Screws: Combination
Series: 95 Line
Std Keyway: Schlage C
Std Latch Backset Dim: 2-3/4"
Std Latch Number: 1834
Std Strike Height: 4-7/8"
Std Strike Number: 1135
Std Strike Type: ASA Curved Lip Strike
Std Strike Width: 1-1/4"
Strike Size: 4-7/8" x 1-1/4"
Subtype: Cylindrical Lock
Supplier: Marks
Type: LOCK SETS
Ul Listing: UL 10C
Unit of Measure: Each
