Attributes

Accessible: Yes

Ada Compliance: Yes

Alternate Codes: 113041, 195RDW/26D, 195RDW26D

Ansi: A156.2

Ansi Function: F87

Baa Qualified: Yes

Backset: 2-3/4"

Bolt Projection: 9/16"

Burglar Rated: No

Category: Commercial Locks, Cylindrical Levers, Lock Sets

Certifications: A156.2, ANSI, UL Listed 3 Hour

Commercial Residential: Commercial

Country of Origin: Usa

Country of origin: USA

Cylinder Included: No

Cylinder Type: IC Core Cylinder

Door Application: Lock Sets

Door Bore Size: 2-1/8"

Door Thickness: 1-5/8"-1-7/8"

Door Thickness Max: 1-7/8"

Door Thickness Min: 1-5/8"

Finish: 626/US26D

Finish Code: 626

Finish Color: Satin Chrome

Finish Description: Satin Chrome

Finish Family: Matte Silver

Fire Rated: Yes

Fire Rating: 120 min

Function: Institution

Grade: Grade 1

Handing: Non-Handed

Installation: Commercial

Keying: Keyed Different

Keys: Cut

Knob/ Lever Design: 195

Knob/ Lever Style: Lever

Latch Bolt Face Type: Square Corner

Latch Bolt Faceplate Size: 2-1/4" x 1-1/8"

Latch Bolt Throw: 1/2"

Latch Bolt Type: Deadlatch

Latch Throw: 9/16"

Latchbolt Type: Deadlatch

Lever Design: American

Leverknob Design: 195 - American Lever

Limited Warranty: Lifetime

Lock Category: Cylindrical Lock

Lock Face Size: 1-1/8" x 2-1/4"

Manufacturer: Marks USA

Of Keys: 2

Origin: USA

Pack Qty: 1

Pins: 6

Restrictions: None

Rose/ Escutcheon: 3-7/16" Diameter, Spring Loaded

Rose/ Escutcheon Size: 2-9/16"

Rose/ Escutcheon Style: Rose

Roseescutcheon Design: 3-7/16" Rose Diameter

Screws: Combination

Series: 95 Line

Std Keyway: Schlage C

Std Latch Backset Dim: 2-3/4"

Std Latch Number: 1834

Std Strike Height: 4-7/8"

Std Strike Number: 1135

Std Strike Type: ASA Curved Lip Strike

Std Strike Width: 1-1/4"

Strike Size: 4-7/8" x 1-1/4"

Subtype: Cylindrical Lock

Supplier: Marks

Tailpiece: Medeco

Type: LOCK SETS

Ul Listing: UL 10C

Unit of Measure: Each
