Attributes

Ship via: Can Ship UPS

Accessible: Yes

Ada Compliance: Yes

Alternate Codes: 122994, 295S/26D, 295S26D

Ansi: A156.2

Ansi Function: F84

Baa Qualified: Yes

Backset: 2-3/4"

Bolt Projection: 9/16"

Bore Hole Diameter: 2-1/8"

Burglar Rated: No

Category: Commercial Locks, Cylindrical Levers, Lock Sets

Certifications: A156.2, ANSI, UL Listed 3 Hour

Commercial Residential: Commercial

Country of Origin: Usa

Country of origin: USA

Cylinder Included: Yes

Cylinder Type: 6-Pin Cylinder

Door Application: Lock Sets

Door Bore Size: 2-1/8"

Door Thickness: 1-5/8"-1-7/8"

Door Thickness Max: 1-7/8"

Door Thickness Min: 1-5/8"

Finish: 626/US26D

Finish Code: 626

Finish Color: Satin Chrome

Finish Description: Satin Chrome

Finish Family: Matte Silver

Fire Rated: Yes

Fire Rating: 120 min

Function: Classroom

Grade: Grade 1

Handing: Non-Handed

Installation: Commercial

Keying: Keyed Different

Keys: Cut

Keyway: Marks C

Knob/ Lever Design: 295

Knob/ Lever Style: Lever

Latch Bolt Face Type: Square Corner

Latch Bolt Faceplate Size: 2-1/4" x 1-1/8"

Latch Bolt Throw: 1/2"

Latch Bolt Type: Deadlatch

Latch Bore Diameter: 1"

Latch Throw: 9/16"

Latchbolt Type: Deadlatch

Lever Design: Crescent

Leverknob Design: 295 - Crescent Lever

Leverknob Design Family: Curved Return Lever

Limited Warranty: Lifetime

Lock Category: Cylindrical Lock

Lock Face Size: 1-1/8" x 2-1/4"

Manufacturer: Marks USA

Of Keys: 2

Origin: USA

Pack Qty: 1

Pins: 6

Projection: 3-1/8"

Restricted Keyway: No

Restrictions: None

Rose/ Escutcheon: 3-7/16" Diameter, Spring Loaded

Rose/ Escutcheon Size: 2-9/16"

Rose/ Escutcheon Style: Rose

Roseescutcheon Design: 3-7/16" Rose Diameter

Screws: Combination

Series: 95 Line

Std Keyway: Schlage C

Std Latch Backset Dim: 2-3/4"

Std Latch Number: 1834A

Std Latch Type: Dead Latch (Guarded)

Std Strike Height: 4-7/8"

Std Strike Number: 1135

Std Strike Type: ASA Curved Lip Strike

Std Strike Width: 1-1/4"

Strike Size: 4-7/8" x 1-1/4"

Subtype: Cylindrical Lock

Supplier: Marks

Type: LOCK SETS

Ul Listing: UL 10C

Unit of Measure: Each
