Morris 82510 Tamper Resistant Duplex Receptacle

Morris 82510 Duplex Receptacle is designed with tamper resistance for enhanced safety in residential and commercial settings. This innovative receptacle features a built-in protective shutter mechanism that effectively prevents the insertion of foreign objects, ensuring peace of mind for users. The clear "TR" marking on the face provides easy identification, making it suitable for both professional and home use. This duplex receptacle is a 2 pole, 3 wire model that supports back and side wiring, accommodating #12 or #14 stranded or solid copper wire, with push-in capabilities for #14 solid wire only. Constructed from durable GE Lexan and equipped with a steel mounting strap, it promises longevity and reliability. The shallow design maximizes wiring room, while the easy-access green hex-head ground screw simplifies the installation process. Additionally, the washer-type break-off plaster ears ensure the best flush alignment, contributing to a polished finish. With a UL 94V-2 flame rating and a temperature range of -40°F to 167°F, the Morris 82510 is built to withstand various conditions. Its large tri-combination head captive screws allow for quick wiring, making it a practical choice for professionals. UL listed and rated for 15 amps at 125 volts, this receptacle is a smart choice for any electrical project.

This Duplex Receptacle is Tamper Resistant.

• 2 pole, 3 wire
• Clear Visible "TR" marking on Face
• Large Tri-Combination Head Captive Screws for quick wiring
• UL listed
• Easy-access Green Hex-Head Ground Screw
• Shallow design for maximum wiring room
• Washer Type Break Off Plaster Ears for best flush alignment
• Temperature Rating: -40°F to 167°F
• UL 94V-2 Flame Rating
• Built-in Protective Shutter Mechanism Designed to Prevent Insertion of Foreign Objects
• Made of GE Lexan, Steel Mounting Strap
• Back & Side Wired
• Accepts #12 or #14 Stranded or Solid Copper Wire (Push-In #14 Solid Only)

Resources

• Catalog PDF page
• Spec Data Sheets
• Spec Sheet
