NGP 119NDKB 48" DKB-finish Aluminum Neoprene Door Shoe is designed to enhance the durability and functionality of your restroom partitions. Constructed from high-quality Aluminum Alloy 6063 with T5 Temper, this door shoe offers excellent strength and resilience. The synthetic EPDM rubber within a polypropylene thermoplastic matrix ensures impressive abrasion resistance, tensile strength, and memory retention. This product is flame-resistant and moisture-resistant, making it ideal for high-traffic environments. It performs effectively across a temperature range of -81°F to 275°F and boasts good resistance to ozone, sunlight, and aging. The dark bronze finish not only provides an attractive aesthetic but also complements various design styles. NGP 119NDKB is BHMA certified to ANSI/BHMA A156.22 performance tests for heat and cold, ensuring it meets rigorous industry standards. It comes with #6 x 3/4" stainless steel SMS fasteners, and the slotted screw holes allow for easy adjustments during installation. For added peace of mind, this door shoe is certified by UL for fire resistance, complying with NFPA standards for hollow metal and wood fire doors. Enhance your commercial restroom with the reliability and performance of the NGP 119NDKB door shoe.
48" DKB-finish Aluminum Neoprene Door Shoe
BHMA: BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
Color: Color is Black
Fasteners: #6 x 3/4" Stainless Steel SMS Furnished
Finish: Dark Bronze Finish
Fire Rated: Flame-Resistant
Length: 48.0"
Material: Aluminum Alloy 6063, T5 Temper
Moisture Resistant: YES
Resistance: Good Resistance to Ozone, Sunlight and Aging
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Standard-4: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Temperature Range: Temperature Range -81°F to 275°F
