NGP 120NDKB 84" DKB-finish Aluminum Neoprene Sponge Seal offers exceptional sealing performance for commercial restroom partitions. Crafted from durable Aluminum Alloy 6063 in T5 Temper, this seal is designed to withstand demanding environments while maintaining its integrity. The advanced elastomeric foam, made from synthetic EPDM rubber embedded in a polypropylene thermoplastic matrix, provides excellent abrasion resistance, tensile strength, and memory, ensuring a reliable seal over time. With a temperature range of -81°F to 275°F, the NGP 120NDKB stands up to extreme conditions while being flame-resistant and moisture-resistant, making it a safe choice for various applications. The seal also boasts good resistance to ozone, sunlight, and aging, ensuring longevity and performance. Installation is straightforward thanks to the provided #6 x 3/4" stainless steel sheet metal screws, which come with slotted screw holes for easy adjustment. The sleek black color and dark bronze finish complement a wide array of restroom designs. BHMA certified to ANSI/BHMA A156.22 performance tests for heat and cold, this product guarantees quality and compliance. Elevate the functionality and durability of your restroom partitions with the NGP 120NDKB seal, a reliable solution for any commercial setting.
Attributes
BHMA: BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
Color: Color is Black
Fasteners: #6 x 3/4" Stainless Steel Sheet Metal Screws Furnished
Finish: Dark Bronze Finish
Fire Rated: Flame-Resistant
Length: 84.0"
Material: Aluminum Alloy 6063, T5 Temper
Moisture Resistant: YES
Patented: Patent Pending Microcellular EPDM
Resistance: Good Resistance to Ozone, Sunlight and Aging
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 96" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: ACOUSTICAL TESTED to ASTM E90 Standard Test Method for Laboratory Measurement of Airborne Sound Transmission Loss of Building Partitions and Elements, and ASTM E2235 Standard Test Method for Determination of Decay Rates for use in Sound Insulation Test Methods. Refer to information on pages G8 thru G10 of our Gasketing catalog for test result data.
Standard-4: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Standard-5: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Temperature Range: Temperature Range -81°F to 275°F
