NGP 12T6 48" Mill Aluminum Thermoplastic Door Shoe offers a robust solution for commercial restroom installations. Constructed from aluminum alloy 6063 in T5 temper, this door shoe is not only economical but also designed for durability with its flame and moisture-resistant properties. The thermoplastic polymer, made from environmentally friendly PVC, enhances its resilience, ensuring it withstands temperature fluctuations from 0°F to 140°F. Measuring a maximum length of 48 inches, the NGP 12T6 provides a versatile fit for various door applications. Its seal features a rigid base with soft dark brown vinyl fins, effectively preventing air and moisture infiltration. Additionally, the door shoe comes with #6 x 3/4" stainless steel SMS fasteners, ensuring secure installation. Certified by UL for both fire and smoke control, the NGP 12T6 meets stringent standards, making it suitable for use on hollow metal and wood fire doors rated up to 3 hours. Its resistance to oxidative degradation ensures longevity, minimizing the risk of hardening or cracking over time. With its blend of functionality and eco-conscious materials, the NGP 12T6 is an excellent choice for building professionals seeking reliable restroom partition hardware.
48" Mill Aluminum Thermoplastic Door Shoe
Color: Oxidative degradation from age and exposure to cold, heat and UV causes hardening, loss of memory and resilience, cracking, crazing and discoloration
Fasteners: #6 x 3/4" stainless steel SMS furnished
Fire Rated: Flame resistant
Length: 48.0"
Material: Mill aluminum
Maximum Length: 48" maximum length
Moisture Resistant: YES
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Temperature Range: Temperature range 0°F to 140°F
