NGP 161SDKB 96" DKB-finish Aluminum Silicone Dense Bulb Perimeter Seal offers superior performance for commercial restroom partitions. Crafted from Aluminum Alloy 6063 with a T5 temper, this perimeter seal is designed to withstand extreme conditions, maintaining flexibility in temperatures ranging from -100°F to 500°F. The dense silicone material, finished in an elegant dark bronze, not only ensures a sleek appearance but also provides excellent resistance to moisture, ozone, UV rays, and aging. This product is flame-resistant and highly recommended for areas utilizing FM200 or Halon fire suppression systems, ensuring safety and compliance with fire standards. The NGP 161SDKB is BHMA certified to ANSI/BHMA A156.22, meeting rigorous performance tests for heat and cold. Installation is made easy with slotted screw holes, allowing for adjustment, and #6 x 3/4" stainless steel sheet metal screws are included. The dense silicone bulb seal effectively prevents air infiltration, smoke, and drafts, making it an ideal choice for maintaining a comfortable and safe restroom environment. Choose the NGP 161SDKB for a durable, reliable, and aesthetically pleasing perimeter seal that meets the highest industry standards.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Excellent Flexibility and Memory
BHMA: BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
Color: Dense Silicone is Black
Fasteners: #6 x 3/4" Stainless Steel Sheet Metal Screws Furnished
Finish: Dark Bronze Finish
Fire Rated: Recommended for Areas Using FM200 or Halon Fire Suppression Systems
Length: 96.0"
Material: Synthetic Rubber Polymer: Siloxane
Moisture Resistant: YES
Resistance: Excellent Resistance to Ozone, UV and Aging
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 96" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Standard-4: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Temperature Range: Temperature Range -100°F to 500°F, Remains Flexible at Extreme Temperatures
