NGP 3038NDKB 84" DKB-finish Aluminum Spring Adjustable Neoprene Perimeter Seal offers outstanding performance and durability for commercial restroom partitions. Constructed from Aluminum Alloy 6063 with a T5 temper, this perimeter seal is designed to withstand the rigors of daily use while maintaining its integrity. The innovative synthetic EPDM rubber, encased in a polypropylene thermoplastic matrix, provides a closed-cell advanced elastomeric foam that excels in abrasion resistance and tensile strength. With a temperature range from -81°F to 275°F, this seal is suitable for a variety of environmental conditions, ensuring effective moisture resistance and flame resistance. Adjustment screws positioned on 10" centers allow for easy adjustments without the need to reposition mounting locations, while the spring-loaded design maintains consistent pressure for optimal sealing. The sleek dark bronze finish adds a touch of elegance, making it an ideal choice for modern restrooms. Certified by BHMA to ANSI/BHMA A156.22 performance tests, this perimeter seal also meets rigorous fire safety standards, making it a reliable component for fire-rated doors. With its robust construction and thoughtful design, the NGP 3038NDKB perimeter seal is a smart investment for any commercial restroom project.
Attributes
BHMA: BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
Color: Color is Black
Fasteners: #6 x 3/4" or #6 x 1-1/2" Stainless Steel SMS Furnished
Finish: Dark Bronze Finish
Fire Rated: Flame-Resistant
Length: 84.0"
Material: Aluminum Alloy 6063, T5 Temper
Moisture Resistant: YES
Resistance: Good Resistance to Ozone, Sunlight and Aging
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 96" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: ACOUSTICAL TESTED to ASTM E90 Standard Test Method for Laboratory Measurement of Airborne Sound Transmission Loss of Building Partitions and Elements, and ASTM E2235 Standard Test Method for Determination of Decay Rates for use in Sound Insulation Test Methods. Refer to information on pages G8 thru G10 of our Gasketing catalog for test result data.
Standard-4: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Standard-5: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Temperature Range: Temperature Range -81°F to 275°F
