NGP 325HDX325HD WELDED 48" ADA Compliant EXTRA Heavy Duty Aluminum Threshold is designed to meet the needs of high-traffic commercial environments. Crafted from durable aluminum alloy 6063 with a T5 temper, this threshold measures 10" wide and stands 1/2" tall, making it an ideal solution for delivery and storage doorways where heavier loads are common. The fluted top provides added traction, ensuring safety and ease of access for all users, particularly in compliance with ADA standards. Weighing in at 3.33 lbs./ft., this threshold is suitable for areas subjected to forklift and vehicular traffic, showcasing its robust construction. Included are #10 x 1-1/2" FH zinc plated wood screws for easy installation, with dark bronze finishes available for DKB thresholds. The mill finish enhances its aesthetic while maintaining resilience against wear and tear. Certified by UL for fire door applications, this threshold is compliant with various safety standards, including NFPA 80 and ANSI/BHMA A156.21, ensuring it can withstand heavy-duty use. The NGP 325HDX325HD is the perfect choice for building professionals seeking reliable and compliant partition hardware solutions.
48" ADA Compliant EXTRA Heavy Duty Aluminum Threshold, 1/2" x 10"
Dimensions: 10" wide x 1/2" tall
Fasteners: #10 x 1-1/2" FH zinc plated wood screws included. Dark bronze supplied with DKB thresholds
Finish: Mill finish
Length: 48.0"
Material: Aluminum alloy 6063, T5 temper
Standard-0: ADA COMPLIANT. Barrier Free Thresholds meet the requirements of the ADA Standard for Accessible Design and ICC/ANSI A117.1 Accessible and Usable Buildings and Facilities.
Standard-1: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-3: ANSI/BHMA CERTIFIED. Certified thresholds comply with American National Standard for Thresholds ANSI/BHMA A156.21 Heavy Duty 10,000 lb. load test and are listed in the BHMA Certified Products Directory.
Wall Thickness: Typical Wall Thickness: .250"
Weight: Weight: 3.33 lbs./ft.
