NGP A625A 36" Anodized Aluminum Nylon Brush Seal delivers superior performance and durability for commercial restroom applications. Crafted from high-quality aluminum alloy 6063 with a T5 temper, this brush seal combines strength with corrosion resistance, ensuring longevity in various environments. The synthetic polymer, polyamide, offers excellent abrasion resistance, flexibility, and memory, making it an ideal choice for high-traffic areas. Designed to withstand a temperature range of -70°F to 425°F, the NGP A625A is moisture resistant and retains insecticides effectively, enhancing its functionality in maintaining a clean and pest-free restroom. It is BHMA Certified to ANSI/BHMA A156.22 standards, ensuring it meets rigorous performance tests for heat and cold. The gray nylon brush provides an efficient barrier while seamlessly blending into any décor. Installation is straightforward, with #6 x 3/4" stainless steel sheet metal screws included and slotted screw holes for easy adjustment. Although not designed to prevent water penetration, this brush seal excels in air infiltration testing and smoke and draft control, certified by UL for use on fire doors rated up to 3 hours. Choose the NGP A625A for a reliable, high-performance solution to enhance your restroom partition systems.
36" Anodized Aluminum Nylon Brush Seal
BHMA: BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
Color: Nylon brush is gray
Fasteners: #6 x 3/4" stainless steel sheet metal screws furnished
Finish: Anodized aluminum
Length: 36.0"
Material: Synthetic polymer: Polyamide
Moisture Resistant: YES
Resistance: Excellent abrasion resistance, flexibility and memory
Ro HS: REACH and RoHS compliant
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Standard-4: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Temperature Range: Temperature range -70°F to 425°F
