NGP B606DKB 72" DKB-finish Aluminum Nylon Brush Seal or Sweep is engineered for durability and performance in commercial restroom environments. Constructed from aluminum alloy 6063 with T5 temper, this product combines a robust design with a sleek dark bronze finish, making it both functional and aesthetically pleasing. The nylon brush, crafted from high-quality Polyamide, offers excellent abrasion resistance, flexibility, and memory, ensuring long-lasting effectiveness in sealing gaps. Designed to withstand extreme conditions, the NGP B606DKB operates effectively within a temperature range of -70°F to 425°F. Its moisture-resistant properties and ability to retain insecticides make it ideal for maintaining cleanliness and comfort in busy facilities. This product is BHMA Certified to ANSI/BHMA A156.22, ensuring it meets rigorous performance tests for heat and cold. Installation is straightforward, with #6 x 3/4" stainless steel sheet metal screws provided, and slotted screw holes allow for easy adjustment. While it excels in many areas, it is important to note that it is not effective against water penetration. The NGP B606DKB is also compliant with REACH and RoHS standards, underlining its commitment to safety and environmental responsibility. Enhance your restroom's efficiency and hygiene with this reliable brush seal or sweep.
Attributes
BHMA: BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
Color: Nylon brush is black
Fasteners: #6 x 3/4" stainless steel sheet metal screws furnished
Finish: Dark bronze finish
Length: 72.0"
Material: Synthetic polymer: Polyamide
Moisture Resistant: YES
Resistance: Excellent abrasion resistance, flexibility and memory
Ro HS: REACH and RoHS compliant
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 96" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Standard-4: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Temperature Range: Temperature range -70°F to 425°F
