NGP BAR 2BR 36" Bronze Bar Support, 1/4" x 1/2" is an essential component for enhancing the structural integrity of threshold assemblies in commercial restrooms. Crafted from Alloy CDA 385, this architectural bronze support features a satin finish that closely resembles US4, offering both durability and aesthetic appeal. With dimensions of 1/2" wide and 1/4" tall, this bar support is designed to provide reliable reinforcement, ensuring smooth operation and stability. This 36-inch long bar support is particularly advantageous for installations requiring ADA compliance, making it suitable for barrier-free thresholds that meet the rigorous standards outlined in the ADA Standard for Accessible Design and ICC/ANSI A117.1. Additionally, it is certified by UL to CAN/ULC-S104 and ANSI/UL10B, ensuring compliance with NFPA 80 and NFPA 252 for hollow metal fire doors rated up to 3 hours, and wood fire doors rated up to 90 minutes. For projects that require positive pressure, this product is also certified by UL to ANSI/UL10C, adhering to IBC, NFPA 80, and NFPA 252 standards. Choose the NGP BAR 2BR for a reliable, compliant, and visually appealing solution for your restroom partition hardware needs.
36" Bronze Bar Support, 1/4" x 1/2"
Application: Used as support under threshold assemblies
Dimensions: 1/2" wide x 1/4" tall
Finish: Alloy CDA 385 architectural bronze satin finish 728 similar to US4
Length: 36.0"
Standard-0: ADA COMPLIANT. Barrier Free Thresholds meet the requirements of the ADA Standard for Accessible Design and ICC/ANSI A117.1 Accessible and Usable Buildings and Facilities.
Standard-1: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
