NGP C627DKB 84" DKB-finish Aluminum Nylon Brush Seal or Sweep is engineered to provide exceptional performance and durability in commercial restroom environments. Made from aluminum alloy 6063 with a T5 temper, this product combines strength with a sleek, dark bronze finish, enhancing your restroom's aesthetic while providing robust functionality. The nylon brush, crafted from polyamide, is designed for excellent abrasion resistance, flexibility, and memory, making it ideal for high-traffic areas. This brush seal effectively retains insecticides and is moisture-resistant, ensuring a hygienic environment. With a temperature range of -70°F to 425°F, it can withstand extreme conditions without compromising integrity. NGP’s C627DKB is also BHMA certified to ANSI/BHMA A156.22 performance tests for heat and cold, confirming its reliability in demanding applications. The included #6 x 3/4" stainless steel sheet metal screws feature slotted screw holes for easy adjustments during installation. Whether you're upgrading existing restroom partitions or outfitting new facilities, the NGP C627DKB is a smart choice that balances functionality and style while adhering to stringent standards, including REACH and RoHS compliance. Experience peace of mind with a product designed for longevity and performance.
Attributes
BHMA: BHMA certified to ANSI/BHMA A156.22 performance tests for heat and cold
Color: Nylon brush is black
Fasteners: #6 x 3/4" stainless steel sheet metal screws furnished
Finish: Dark bronze finish
Length: 84.0"
Material: Synthetic polymer: Polyamide
Moisture Resistant: YES
Resistance: Excellent abrasion resistance, flexibility and memory
Ro HS: REACH and RoHS compliant
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 96" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Standard-4: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Temperature Range: Temperature range -70°F to 425°F
