NGP GAP90NDKB 96" Fire Door Head/Jamb Gap Solution is expertly engineered for fire-rated doors, providing an effective solution for excessive clearance between the door and frame. This UL certified product accommodates gaps over 1/8" up to 3/8" for 60 and 90-minute fire doors, as well as up to 9/16" for 20 and 45-minute fire doors. Designed specifically for door frame stops less than 1-3/8" wide, it ensures compliance with fire safety standards while restricting the passage of smoke. The GAP90NDKB is available in lengths of 36", 48", 84", and 96", making it versatile for various applications. Its non-handed design allows for easy installation regardless of door orientation. The striking charcoal color complements most restroom settings, enhancing both functionality and aesthetics. For optimal latchbolt engagement, it may be necessary to pair this product with an NGP Strike Shim (models 9275 or 9225). Certified for use in both the US and Canada, this patented solution (US Patent 9,273,510 B2) meets stringent standards, including ANSI/UL10C and ANSI/UL10B, ensuring reliability and performance. Consider the NGP GAP90NDKB for a dependable and compliant fire door solution.
96" Fire Door Head/Jamb Gap Solutionsfor Narrow SoffitUp To 90 Minutes
Ship via: No UPS - Common Carrier Only
Application: Designed for Use Where Door Frame Stop is Less Than 1-3/8" Wide
Certifications: Certified for use in US and Canada
Color: Charcoal
Handing: Non-Handed
Length: 96.0"
Patented: Patented: US Patent 9,273,510 B2
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 96" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standard-0: POSITIVE PRESSURE – CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal and Wood fire doors rated up to 90 minute with excessive door and frame clearances, measuring up to 3/8"; and rated up to 45 minutes with excessive clearances up to 9/16".
Standard-1: CERTIFIED by UL to ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal and Wood fire doors rated up to 90 minute with excessive door and frame clearances, measuring up to 3/8"; and rated up to 45 minutes with excessive clearances up to 9/16".
