Norton Closers 7500696 Adjustable Heavy Duty Surface Mount Door Closer with Sex Nuts in Gold Finish combines durability and performance for a reliable door control solution. Designed with a robust rack and pinion mechanism, this closer ensures smooth operation and longevity, making it ideal for high-traffic environments. The 7500696 model features heavy-duty arms and an adjustable spring size ranging from 1 to 6, allowing for precise control over door movement. Its non-handed design simplifies installation, accommodating both right and left-hand doors effortlessly. The backcheck positioning valve protects walls from damage by controlling the door's opening swing, while the molded plastic cover offers added protection and aesthetic appeal. Constructed from cast aluminum, this surface-mounted closer is built to withstand rigorous use, ensuring a long-lasting performance backed by a limited 25-year warranty. Measuring 3-1/2" x 13-5/8", it is designed for pull-side mounting with a rectangular mounting hole pattern of 2-3/8" x 6-3/4". The gold finish not only enhances its durability but also adds a touch of elegance to any entrance. With UL and cUL listings, the Norton 7500696 is a trusted choice for those seeking quality and reliability in door control solutions.
Adjustable Heavy Duty Surface Mount Door Closer with Sex Nuts Gold Finish
Norton Door Controls offers a comprehensive line of door controls designed and manufactured to ensure superior performance and reliability. Norton Door Controls refined the rack and pinion closer and the concept of valve controlled backcheck for hydraulic door closers. Along the way there have been a variety of other innovations, including aluminum alloy body, narrow style, non-handed closers, adjustable backcheck, speed adjustments and special application arms.
Manufacturer surcharge: $ 0.0
Accessible: Yes
Ada Compliance: Yes
Ansi: ANSI A156.4
Arm Type: Regular Arm
Baa Qualified: Yes
Back Check: Adjustable
Category: Door Closers and Accessories
Closer Size: Adj. 1 to 6
Closer Type: Surface Mounted Closer
Cold Weather Fluid: Yes
Commercial Residential: Commercial
Country of Origin: Usa
Country of origin: USA
Cover: Plastic
Dimension: 3-1/2" x 13-5/8"
Finish: Gold
Finish Code: 696
Finish Description: Satin Brass Painted
Finish Family: Matte Brass
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: Regular
Grade: Grade 1
Hand: Non-Handed
Handing: Non-Handed
Hazardous Material: NO
Hold Open: No
Installation: Commercial
Limited Warranty: 25 Years
Manufacturer Warranty: Limited 25 Year Warranty
Material: Cast Aluminum
Mounting Group: Hydraulic
Mounting Hole Pattern: 2-3/8" x 6-3/4" Rectangular Mounting
Mounting Location: Push or Pull Side
Mounting Style: Tri Mount
No Of Inners: 1
Order_ Qty: 1
Origin: USA
Pack Height: 3.5"
Pack Height 2: 7.75"
Pack Length: 15.25"
Pack Length 2: 15.75"
Pack Qty: 1
Pack Volume: 333.59 in³
Pack Volume 2: 1556.3 in³
Pack Width: 6.25"
Pack Width 2: 12.75"
Series: 7500 Series
Ship Weight: 13 lbs.
Spring Size: Adjustable 1-6 Size
Subcategory: Surface Mount Closers
Subtype: Surface Mount
Type: Surface
Ul Listing: UL 10C
Ul Listing Type: UL / cUL / UL10C Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 4
