Richelieu 2716657100 FREEflap Forte Lift System combines practicality with robust functionality, making it an essential addition to your cabinetry solutions. This compact lifter is designed to handle a door height range of 15 3/4 to 23 5/8 inches, perfectly accommodating various kitchen and furniture applications. The FREEflap system features an integrated multi-position stop, ensuring that the door remains securely in any position, enhancing both safety and ease of use. With a hinge opening angle of +107°, the lift-up opening mechanism allows for seamless access to your cabinets, providing an unobtrusive design that complements modern aesthetics. Finished in a light gray color, this system not only performs exceptionally but also looks great in any environment. The power factor ranges from 3,041 to 4,180, indicating a strong capability to support heavier doors without compromising performance. This product can ship via UPS, making it convenient for your procurement needs. The FREEflap Forte Lift System is ideal for building professionals and knowledgeable homeowners seeking reliable, efficient, and stylish cabinetry solutions. Enhance your kitchen or furniture design with this versatile and durable lift system from Richelieu.
FREEflap Forte Lift System
Brand: Richelieu
Compatible with aluminum frame doors: Yes
Door Height: 400 to 600 mm
Finish: Gray
Hinge Opening Angle: +107°
Max weight for door height <= to 350 mm: 6.7 to 14.3 kg
Max weight for door height <= to 375 mm: 6.3 to 13.1 kg
Max weight for door height <= to 400 mm: 5.9 to 12.4 kg
Max weight for door height <= to 425 mm: 5.6 to 11.6 kg
Max weight for door height <= to 450 mm: 5.2 to 10.9 kg
Max weight for door height <= to 475 mm: 4.9 to 10.3 kg
Max weight for door height <= to 500 mm: 4.7 to 9.7 kg
Max weight for door height <= to 525 mm: 4.4 to 9.2 kg
Max weight for door height <= to 550 mm: 4.2 to 8.8 kg
Max weight for door height <= to 575 mm: 4 to 8.4 kg
Max weight for door height <= to 600 mm: 3.8 to 8 kg
Max weight for door height <= to 625 mm: 3.6 to 7.6 kg
Max weight for door height <= to 650 mm: 3.4 to 7.3 kg
Model: FREEflap forte
Opening Angle: 107°
Opening Types: Lift-Up Opening
Opening Types NEW: Lift-Up Opening
Power Factor: 3 041 to 4 180
Product #: 2716657100
Product number: 2716657100
Product №: 2716657100
System Name: E
System Type: Soft-Close
Unit: Box
Unit 1: skid - 152
Unit 2: skid - 152
