Richelieu 271665930 FREEflap Forte Lift System is the ideal solution for those seeking a practical and compact lifter for their cabinetry. Known as the "little toughie" in the lifter family, this system combines strength and reliability with a sleek design. The integrated multi-position stop feature ensures that the front can securely rest in any desired position, providing both convenience and safety during use. Designed for door heights ranging from 15 3/4 to 23 5/8 inches, this lift system accommodates various cabinetry styles. Its hinge opening angle of +107° allows for easy access and visibility into your cabinets, making it perfect for kitchen and storage solutions. The FREEflap operates via a lift-up opening mechanism that streamlines the user experience. Finished in a clean white, the Richelieu FREEflap Forte not only performs well but also blends seamlessly with modern home aesthetics. With a power factor of 3,041 to 4,180, it demonstrates impressive efficiency and capability. This product ships conveniently via UPS, ensuring that it arrives promptly for your next project. Elevate your cabinetry with the reliable, stylish, and functional FREEflap Forte Lift System from Richelieu.
FREEflap Forte Lift System
Brand: Richelieu
Compatible with aluminum frame doors: Yes
Door Height: 400 to 600 mm
Finish: White
Hinge Opening Angle: +107°
Max weight for door height <= to 350 mm: 6.7 to 14.3 kg
Max weight for door height <= to 375 mm: 6.3 to 13.1 kg
Max weight for door height <= to 400 mm: 5.9 to 12.4 kg
Max weight for door height <= to 425 mm: 5.6 to 11.6 kg
Max weight for door height <= to 450 mm: 5.2 to 10.9 kg
Max weight for door height <= to 475 mm: 4.9 to 10.3 kg
Max weight for door height <= to 500 mm: 4.7 to 9.7 kg
Max weight for door height <= to 525 mm: 4.4 to 9.2 kg
Max weight for door height <= to 550 mm: 4.2 to 8.8 kg
Max weight for door height <= to 575 mm: 4 to 8.4 kg
Max weight for door height <= to 600 mm: 3.8 to 8 kg
Max weight for door height <= to 625 mm: 3.6 to 7.6 kg
Max weight for door height <= to 650 mm: 3.4 to 7.3 kg
Model: FREEflap forte
Opening Angle: 107°
Opening Types: Lift-Up Opening
Opening Types NEW: Lift-Up Opening
Power Factor: 3 041 to 4 180
Product #: 271665930
Product number: 271665930
Product №: 271665930
System Name: E
System Type: Soft-Close
Unit: Box
Unit 1: skid - 152
Unit 2: skid - 152
