Richelieu 39C355B21180 COMPACT BLUMOTION 39C Hinges 110 is expertly crafted for framed cabinets, providing an exceptional blend of functionality and style. The integrated soft-closing function ensures that doors close quietly and smoothly, enhancing the user experience in any kitchen or cabinetry design. This feature can be easily deactivated for lighter or smaller doors, allowing for versatile application without compromising on quality. Designed for full overlay doors, these hinges accommodate a minimum cabinet thickness of 5/8 inch and a door thickness of the same measurement. The hinge boasts a generous opening angle of +110°, facilitating easy access to cabinet interiors. Made from durable steel and finished in sleek nickel, the 39C355B21180 adds a contemporary touch while ensuring long-lasting performance. Installation is straightforward with a screw-on fixing type, and the wraparound mounting type allows for secure attachment. The milling depth and diameter requirements of 1/2 inch and 1 3/8 inches, respectively, make this hinge a practical choice for standard door applications. Packaging is offered per unit, making it easy to order the exact quantity needed for your project. Elevate your cabinetry with Richelieu's COMPACT BLUMOTION hinge for a refined finishing touch.
COMPACT BLUMOTION 39C Hinges 110
Brand: Blum
Cabinet Thickness: Min. 5/8 in*
Cabinet Type: Face Frame
Closing Mechanism: Soft-Closing
Door Position: Full Overlay
Door Thickness: 5/8 in*
Finish: Nickel
Fixing Type: Screw-On
Hinge Opening Angle: +110°
Hinge Type: COMPACT BLUMOTION
Material: Steel
Mechanism: Soft-Closing
Milling Depth: 1/2 in*
Milling Diameter: 1 3/8 in*
Mounting Type: Wrap-around Mount
Overlay: 1 5/16 in
Packaging format: Per unit
Product #: 39C355B21180
Product number: 39C355B21180
Screw/ Nail: Not included
Unit 1: case - 300
Use Type: Standard Door
