Richelieu 7538930180 J95 Heavy Duty Concealed Hinge offers exceptional support for both wood and glass doors, making it a versatile choice for any project. This heavy-duty European hinge can accommodate wood doors weighing up to 88 lbs (40 kg) and glass doors up to 77 lbs (35 kg), ensuring durability and reliability. For optimal performance, the hinge dimensions vary based on the thickness of the glass. When using an 8 mm glass panel, the maximum door dimensions are 800 mm (31.5 in) W x 1850 mm (72 in) H. If opting for a 10 mm glass panel, the dimensions adjust slightly to 700 mm (27.5 in) W x 1850 mm (72 in) H. For heavier applications, utilizing three hinges allows for a maximum height of 2000 mm (78 in), providing added stability. Designed for inset doors, this hinge features a screw-on fixing type and a nickel finish that complements various aesthetics. With a hinge opening angle of +95°, it allows for easy access while the spring closing mechanism ensures smooth operation. Please note that mounting plates are sold separately, and the hinge requires 6 x M5 or equivalent screws for installation. The Richelieu J95 hinge is a reliable solution for both standard and glass door applications.
J95 Heavy Duty Concealed Hinge
Important information
Brand: Sugatsune
Door Position: Inset
Finish: Nickel
Fixing Type: Screw-On
Hinge Opening Angle: +95°
Load Capacity: 55.1 lb*
Mechanism: Spring Closing
Overlay: 0 in*
Product #: 7538930180
Production Time: In Stock
Thickness of Glass: 5/16 to 13/32 in*
Use Type: Standard Door, Glass
