Richelieu BP39C35520180S COMPACT 39C Hinge 110 offers a superior solution for face frame cabinet installations. Designed for versatility, these concealed hinges accommodate both small and large overlays, making them ideal for a wide range of applications. Their adjustable side, height, and depth dimensions ensure a perfect fit for various cabinet configurations. Crafted from durable steel with a sleek nickel finish, this hinge not only provides strength but also enhances the aesthetic of your cabinetry. The +110° hinge opening angle allows for smooth and unobstructed access, while the spring closing mechanism ensures that doors close softly and securely. With a maximum cabinet and door thickness of 3/4 inch, these hinges are compatible with standard door types and are designed for wraparound type mounting. Installation is straightforward, thanks to the included screws and the precise milling requirements of 1/2 inch depth and 1 3/8 inch diameter. Each package contains two units, making it easy to equip multiple doors or cabinets. Whether you're a building professional or an informed homeowner, the Richelieu BP39C35520180S COMPACT hinge combines functionality with style, making it a must-have for your next project.
COMPACT 39C Hinge 110
Brand: Blum
Cabinet Thickness: Max. 3/4 in*
Cabinet Type: Face Frame
Closing Mechanism: Spring Closing
Door Position: Full Overlay
Door Thickness: Max. 3/4 in
Finish: Nickel
Fixing Type: Screw-On
Hinge Opening Angle: +110°
Hinge Type: COMPACT
Material: Steel
Mechanism: Spring Closing
Milling Depth: 1/2 in
Milling Diameter: 35 mm
Mounting Type: Wrap-around Mount
Overlay: 1 1/4 in
Packaging format: Bag of 2 units
Product #: BP39C35520180S
Product number: BP39C35520180S
Required Frame Width: 19 mm
Screw/ Nail: #10 x 3/4" Quadrex Pan Head (Included), #6 x 5/8" Quadrex Flat Head (Included)
Unit: Bag of 2 units
Unit 2: carton - 10
Unit 3: case - 120
Use Type: Standard Door
