Richelieu COMPACT BLUMOTION 39C Hinges 110 are expertly designed for framed cabinets, ensuring a perfect blend of functionality and style. Featuring an integrated soft-closing mechanism, these hinges guarantee that doors close quietly and smoothly, enhancing the overall user experience. For those occasions when smaller or lighter doors are used, the BLUMOTION function can be easily deactivated, allowing for consistent high-quality movement across your cabinetry. Crafted from durable steel with a sleek nickel finish, these hinges are tailored for full overlay applications and accommodate door thicknesses of 5/8 inch. The hinges support a hinge opening angle of +110°, providing ample access while maintaining aesthetic appeal. Designed for use with cabinets that have a minimum thickness of 5/8 inch, they are installed using a screw-on fixing type and a wraparound type mounting for added stability. With a milling depth of 1/2 inch and a diameter of 1 3/8 inches, the COMPACT BLUMOTION hinges are versatile and easy to install. Sold individually, they come ready for standard door applications, making them a reliable choice for any cabinetry project. Elevate your cabinet design with the dependable performance of Richelieu's COMPACT BLUMOTION 39C Hinges.
COMPACT BLUMOTION 39C Hinges 110
Brand: Blum
Cabinet Thickness: Min. 5/8 in*
Cabinet Type: Face Frame
Closing Mechanism: Soft-Closing
Door Position: Full Overlay
Door Thickness: 5/8 in*
Finish: Nickel
Fixing Type: Screw-On
Hinge Opening Angle: +110°
Hinge Type: COMPACT BLUMOTION
Material: Steel
Mechanism: Soft-Closing
Milling Depth: 1/2 in*
Milling Diameter: 1 3/8 in*
Mounting Type: Wrap-around Mount
Overlay: 1 1/2 in
Packaging format: Per unit
Product #: 39C355B24180
Product number: 39C355B24180
Screw/ Nail: Not included
Unit 1: case - 300
Use Type: Standard Door
