Richelieu FRAKFEPWSN9 Wind Lift System - Push is an innovative solution for flap doors, combining compact design with elegance and functionality. This lift door system is particularly well-suited for kitchen applications, where space is often at a premium. Its sleek profile ensures that it integrates seamlessly into your cabinetry while maintaining a discreet appearance. The Wind Lift System features an integrated damping mechanism, allowing for soft closing, as well as a push-to-open function for doors without handles. This versatility enhances both convenience and style in your kitchen environment. It accommodates door thicknesses ranging from 16 mm (5/8") to a maximum of 28 mm (1 1/8"), with an overlay capacity of 16 mm to 20 mm. Adjustability is a key aspect of this system, offering depth adjustments of -1 mm to +3 mm, lateral adjustments of +2 mm to -2 mm, and height adjustments of +2 mm to -2 mm. Designed for wooden doors with a height range of 8 21/32 to 23 5/8 inches and a hinge opening angle of +94°, the Wind Lift System ensures a reliable and flexible installation. With the Richelieu FRAKFEPWSN9, elevate your cabinetry with a sophisticated lift door solution that marries practicality with modern design.
Wind Lift System - Push
Brand: Salice
Door Height: 220 to 400 mm
Door Type: Wood Door
Hinge Opening Angle: +94°
Load Capacity: 1 to 5.2 kg
Model: Original
Opening Angle: 94°
Opening Types: Lift-Up Opening
Opening Types NEW: Lift-Up Opening
Power Factor: 400 to 800
Product #: FRAKFEPWSN9
Product number: FRAKFEPWSN9
Product №: FRAKFEPWSN9
System Name: Wind W
Unit: Box
Unit 1: case - 10
Unit 2: case - 10
