Richelieu H030C2R7W99 Hinges for Negative Angle Doors are engineered for frameless cabinets, offering a reliable solution for full overlay installations. Designed specifically for cabinets with a -30° angle, these hinges ensure seamless functionality and durability. With a drilling distance on the door ranging from 3 to 6 mm (1/8 to 11/32 in), installation is straightforward and adaptable to various door configurations. The self-closing doweled version features a 13 mm deep metal cup, providing robust support and enhanced longevity. The spring closing mechanism guarantees smooth operation, making it ideal for high-traffic areas where ease of use is paramount. Finished in nickel, these hinges not only perform well but also add a sleek touch to any cabinetry design. Packed in boxes of 150, the H030C2R7W99 is ready for large-scale projects and can ship via UPS, ensuring quick delivery. With a production time in stock, you can count on prompt availability when you need it most. Choose Richelieu's H030C2R7W99 hinges for your angle cabinet needs and experience the perfect blend of functionality and style.
200 Series - Negative Angled Hinges 120
Brand: Salice
Cabinet Angle: -30°
Cabinet Type: Frameless
Closing Mechanism: Spring Closing
Diameter: 1 3/8 in*
Door Position: Full Overlay
Door Thickness: 5/8 to 1 1/32 in*
Drilling Distance: 3 to 9 mm
Finish: Nickel
Fixing Type: Dowel
Hinge Opening Angle: +120°
Mechanism: Spring Closing
Milling Depth: 7/16 in*
Milling Diameter: 1 3/8 in*
Product #: H030C2R7W99
Product number: H030C2R7W99
Product №: H030C2R7W99
Production Time: Stock
Series: 200 Series
Unit 1: case - 150
Use Type: Angle Cabinet
