Richelieu H094C2PAP99 Series 200 Concealed Hinge - 94 offers an innovative solution for frameless cabinetry, seamlessly integrating style and functionality. This hinge is engineered to accommodate both inset door positions and provides an impressive opening angle of +94°, allowing for easy access to your cabinet interiors. Featuring independent and compensation adjustments, the Series 200 hinge ensures precise alignment, making installation straightforward and efficient. The safety stop device enhances usability by preventing the door from overextending, whether it’s used in symmetrical or asymmetrical configurations. Snap-on mounting simplifies the installation process, while its adaptability to all Domi series quick-release mounting plates adds versatility to your project. Constructed with a sleek nickel finish, this hinge not only performs well but looks great too, complementing modern cabinetry aesthetics. With a milling depth of 5/8 inch and a milling diameter of 1 3/8 inches, it fits seamlessly into your design, supporting a load capacity of up to 10 pounds. The Richelieu H094C2PAP99 hinge is perfect for standard doors, ensuring your cabinetry remains functional and stylish for years to come. With stock availability, you can trust Richelieu for timely delivery on your projects.
200 Series - Concealed Hinges 94 for Thick Door
Brand: Salice
Cabinet Type: Frameless
Closing Mechanism: Free Swing
Crank: 21/32 in*
Diameter: 1 3/8 in*
Door Position: Inset
Door Thickness: 3/4 to 1 3/8 in*
Drilling Distance: 3 to 9 mm
Finish: Nickel
Fixing Type: Screw-On
Hinge Opening Angle: +94°
Load Capacity: 10 lb
Mechanism: Free Swing
Milling Depth: 15.5 mm
Milling Diameter: 35 mm
Overlay: 0.0781 in
Product #: H094C2PAP99
Product number: H094C2PAP99
Product №: H094C2PAP99
Production Time: Stock
Series: 200 Series
Unit 1: case - 300
Use Type: Standard Door
