Richelieu H110C2R6D99 Series 200 Concealed Hinges - 110 offer a sophisticated solution for any project requiring concealed hinge applications. Engineered by Salice, this integrated hinge system is designed for versatility and ease of use. One of the standout features is its independent and compensation adjustment, allowing for precise alignment and operation. The hinges come equipped with a safety stop device that functions effectively in both symmetrical and asymmetrical installations. Installation is simplified with a snap-on mounting system, and the hinges are compatible with all Domi series quick-release mounting plates, enhancing their adaptability. Designed for a door overlay of 1/2 inch (12.7 mm) and accommodating door thicknesses ranging from 5/8 to 1 1/32 inches, these hinges are suitable for a variety of standard door applications. With a hinge opening angle of +110°, they allow for excellent accessibility. The nickel finish adds a touch of elegance while ensuring durability. Additional specifications include a milling depth of 7/16 inches and a milling diameter of 1 3/8 inches, making them a practical choice for professional-grade installations. For those seeking reliability and functionality in concealed hinges, the Richelieu H110C2R6D99 does not disappoint.
200 Series - Concealed Hinge 110
Brand: Salice
Cabinet Type: Frameless
Closing Mechanism: Spring Closing
Crank: 3/16 in*
Diameter: 1 3/8 in*
Door Position: Full Overlay
Door Thickness: 5/8 to 1 1/32 in*
Drilling Distance: 3 to 6 mm
Finish: Nickel
Fixing Type: Dowel
Hinge Opening Angle: +110°
Load Capacity: 10 lb
Mechanism: Spring Closing
Milling Depth: 7/16 in*
Milling Diameter: 1 3/8 in*
Overlay: 0.5 in
Product #: H110C2R6D99
Product number: H110C2R6D99
Product №: H110C2R6D99
Production Time: Stock
Series: 200 Series
Unit 1: case - 300
Use Type: Standard Door
