Richelieu H110C2R6G99 Series 200 Concealed Hinges - 110 offer an innovative solution for projects requiring concealed hinges. Designed as part of the Salice Series 200, these hinges provide exceptional flexibility with independent and compensation adjustment features, ensuring a perfect fit for your cabinetry. The hinges are equipped with a safety stop device, accommodating both symmetrical and asymmetrical door applications. These hinges support half overlay installation and are suitable for door thicknesses ranging from 5/8 to 1 1/32 inches. Their snap-on mounting simplifies installation, making them adaptable to all Domi series quick-release mounting plates, which can save valuable time on the job site. With a hinge opening angle of +110°, they allow for easy access while maintaining a sleek aesthetic. Crafted with a nickel finish, the H110C2R6G99 model not only delivers durability but also complements modern kitchen designs beautifully. The spring closing mechanism ensures that doors securely close, enhancing both functionality and safety. With a milling diameter of 1 3/8 inches and a depth of 7/16 inches, this hinge is engineered for standard door use. Trust Richelieu for quality solutions that elevate your cabinetry projects.
200 Series - Concealed Hinge 110
Brand: Salice
Cabinet Type: Frameless
Closing Mechanism: Spring Closing
Crank: 11/32 in*
Diameter: 1 3/8 in*
Door Position: Half Overlay
Door Thickness: 5/8 to 1 1/32 in*
Drilling Distance: 3 to 6 mm
Finish: Nickel
Fixing Type: Dowel
Hinge Opening Angle: +110°
Load Capacity: 10 lb
Mechanism: Spring Closing
Milling Depth: 7/16 in*
Milling Diameter: 1 3/8 in*
Overlay: 0.3125 in
Product #: H110C2R6G99
Product number: H110C2R6G99
Product №: H110C2R6G99
Production Time: Stock
Series: 200 Series
Unit 1: case - 300
Use Type: Standard Door
