Richelieu H120C279A99 Series 200 Concealed Hinge 120 offers a sophisticated solution for frameless cabinet applications where concealed hinges are essential. This hinge features independent and compensation adjustments, allowing for precise alignment during installation. With a safety stop device, it supports both symmetrical and asymmetrical door designs, ensuring reliability and ease of use. The snap-on mounting system simplifies installation, making it adaptable to all Domi series quick-release mounting plates. This versatility is complemented by a hinge opening angle of +120°, providing ample access to cabinet interiors. The hinge is designed for full overlay doors, with an overlay measurement of 0.75 inches, which enhances the overall aesthetic of your cabinetry. Crafted from durable materials with a sleek nickel finish, the H120C279A99 hinge boasts a load capacity of 10 pounds, accommodating a variety of door styles. It utilizes a spring closing mechanism for smooth operation, enhancing the overall user experience. This product is readily available with stock production time and can be shipped conveniently via UPS. Whether you’re a building professional or a discerning homeowner, the Richelieu Series 200 hinge is an excellent choice for your cabinetry needs.
200 Series - Concealed Hinges 120
Brand: Salice
Cabinet Thickness: 5/8 to 1 1/32 in*
Cabinet Type: Frameless
Closing Mechanism: Spring Closing
Crank: 0 in*
Diameter: 1 3/8 in*
Door Position: Full Overlay
Drilling Distance: 3 to 6 mm
Finish: Nickel
Fixing Type: Quick Assembly
Hinge Opening Angle: +120°
Load Capacity: 10 lb
Mechanism: Spring Closing
Milling Depth: 7/16 in*
Milling Diameter: 1 3/8 in*
Overlay: 0.75 in
Product #: H120C279A99
Product number: H120C279A99
Product №: H120C279A99
Production Time: Stock
Series: 200 Series
Unit 1: case - 300
Use Type: Standard Door
