Richelieu WEBKIT1010613 HAWA JUNIOR B Series Sliding Door SystemRichelieu WEBKIT1010613 HAWA JUNIOR B Series Sliding Door System offers a robust solution for sliding wood doors, accommodating weights from 88 lb to 550 lb (40 kg to 250 kg). Designed with a low profile rebate/mortise mount suspension plate, this system ensures a minimal gap between the top of the door and the upper track, eliminating the need for a fascia. The integrated track stopper features an adjustable retaining device that effectively resists door bounce back, enhancing the overall functionality. With versatile track options available in various lengths, this system supports single sliding, biparting, and bypassing applications, making it an ideal choice for both commercial and residential projects. The HAWA JUNIOR B Series guarantees smooth and quiet operation, thanks to its premium performance and long-lasting trolleys. For doors weighing between 88 lb and 264 lb (40 kg to 120 kg), the optional SoftMove soft/self-closing mechanism can be added to provide enhanced comfort and convenience. Suitable for applications such as room dividers, pocket doors, and low headroom settings, this system is designed for top-hung installation. With a satin aluminum finish and adjustable configurations, the Richelieu HAWA JUNIOR B Series combines style and functionality, making it a superior choice for modern spaces.
HAWA JUNIOR B Series Sliding Door System
The HAWA JUNIOR B Series sliding wood door systems for doors weighing 88 lb to 550 lb (40 kg to 250 kg) per door.
- Low profile rebate/mortise mount suspension plate for the top of the door
- Minimal gap between the top of the door and upper track, does not require a fascia
- Integrated track stopper with adjustable retaining device to resist door bounce back
- Versatile track options in various lengths for single sliding, biparting, and bypassing applications
- Smooth and quiet premium performance and long-lasting trolleys
- Available SoftMove soft/self-closing mechanism sold separately for doors weighing from 88 lb to 264 lb (40 kg to 120 kg) per door
The HAWA JUNIOR B Series is an ideal solution for premium commercial and residential projects, room dividers, pocket doors, wall partitions, and low headroom applications.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Sliding Wall / Standard Access Door
Brand: Hawa
Detailed Door Movement: Single Sliding
Door Height: Max. 3 660 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inside Frame
Door Thickness: 38 to 57 mm
Door Width: Max. 1 500 mm
Finish: Satin Aluminum
Length - Overall Dimensions: 9 ft 10 in*
Load Capacity: 267 to 353 lb*
Number of Doors: 1
Overall Length: 3 m
Product #: WEBKIT1010613
Product number: WEBKIT1010613
Product №: WEBKIT1010613
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: None
Soft- Closing: No
Track Finish: Satin Aluminum
Track Length: 3 m
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 160 kg
