Richelieu WEBKIT1010615 HAWA JUNIOR B Series Sliding Door SystemRichelieu WEBKIT1010615 HAWA JUNIOR B Series Sliding Door System offers a robust solution for both commercial and residential applications, accommodating doors weighing between 88 lb and 550 lb. This system features a low-profile rebate/mortise mount suspension plate, ensuring minimal gap between the door and the upper track, eliminating the need for a fascia. The integrated track stopper comes with an adjustable retaining device, effectively preventing door bounce back for enhanced safety. Designed for versatility, the HAWA JUNIOR B Series supports various track options and configurations, including single sliding, biparting, and bypassing applications. Its premium trolleys ensure a smooth and quiet operation, making it ideal for high-traffic environments. The system can be adapted with the optional SoftMove mechanism for doors weighing from 88 lb to 264 lb, providing a gentle self-closing feature. This top-hung system accommodates door heights ranging from 78 3/4 to 157 inches and widths from 39 3/8 to 78 3/4 inches, with a thickness of 1 9/16 to 3 5/32 inches. Finished in satin aluminum, the HAWA JUNIOR B Series is perfect for room dividers, pocket doors, wall partitions, and low headroom spaces, making it an excellent choice for modern design aesthetics.
HAWA JUNIOR B Series Sliding Door System
The HAWA JUNIOR B Series sliding wood door systems for doors weighing 88 lb to 550 lb (40 kg to 250 kg) per door.
- Low profile rebate/mortise mount suspension plate for the top of the door
- Minimal gap between the top of the door and upper track, does not require a fascia
- Integrated track stopper with adjustable retaining device to resist door bounce back
- Versatile track options in various lengths for single sliding, biparting, and bypassing applications
- Smooth and quiet premium performance and long-lasting trolleys
- Available SoftMove soft/self-closing mechanism sold separately for doors weighing from 88 lb to 264 lb (40 kg to 120 kg) per door
The HAWA JUNIOR B Series is an ideal solution for premium commercial and residential projects, room dividers, pocket doors, wall partitions, and low headroom applications.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Sliding Wall / Standard Access Door
Brand: Hawa
Detailed Door Movement: Single Sliding
Door Height: Max. 3 660 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inside Frame
Door Thickness: Min. 40 mm
Door Width: Max. 2 000 mm
Finish: Satin Aluminum
Length - Overall Dimensions: 13 ft 1 in*
Load Capacity: 355 to 551 lb*
Number of Doors: 1
Overall Length: 4 m
Product #: WEBKIT1010615
Product number: WEBKIT1010615
Product №: WEBKIT1010615
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: None
Soft- Closing: No
Track Finish: Satin Aluminum
Track Length: 4 m
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 250 kg
