Richelieu WEBKIT1219940 Grant TopLine Straight Sliding Door SystemRichelieu WEBKIT1219940 Grant TopLine Straight Sliding Door System combines strength and elegance, making it an ideal choice for both residential and commercial spaces. This system supports wood doors weighing up to 500 lb (227 kg), ensuring durability for high-traffic areas. With precision ball bearing wheel trolleys that glide effortlessly on aluminum box tracks, it guarantees smooth operation every time. Designed for versatility, the Grant TopLine accommodates single, biparting, and bypassing door applications, enhancing accessibility and style in closets, walk-in closets, cabinets, and storage areas. The system is available in two packaging formats: a complete kit that includes hardware and track or bulk options for customized selections. For added convenience, a Silent System soft-close and soft-open mechanism can be incorporated for doors up to 325 lb (147 kg), providing a quiet and gentle operation. The system can handle doors with a maximum height of 9 ft 10 in* and a minimum thickness of 31/32 in*, while door widths range from 30 to 94 1/2 in*. Installation is straightforward with ceiling mounting, making it a seamless addition to any space. Choose the Richelieu Grant TopLine system for a blend of functionality, quality, and modern design.
Grant TopLine Straight Sliding Door System
The Grant TopLine Straight Sliding Door System, featuring Grant TopLine SD, Grant TopLine HD and Grant TopLine XHD, is designed for wood doors weighing up to 500 lb (227 kg) each.
- Precision ball bearing wheel trolleys run on aluminum box tracks
- Silent System soft-close and soft-open mechanism available separately for doors weighing up to 325 lb (147 kg) each.
- Available in 2 packaging formats: kit (hardware and track), bulk (hardware and track selected separately)
These models are designed for commercial and residential use with single, biparting, and bypassing door applications.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Closet and Walk-In Closet, Cabinet, Storage
Brand: Grant Hettich
Detailed Door Movement: Single Sliding
Door Height: Max. 3 000 mm
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: Min. 25 mm
Door Width: 762 to 2 400 mm
Grant Top Line Model: Grant TopLine SD
Length - Overall Dimensions: 72 in*
Load Capacity: Max. 150 lb*
Number of Doors: 1
Overall Length: 1 829 mm
Packaging format: Per unit
Product #: WEBKIT1219940
Product number: WEBKIT1219940
Product №: WEBKIT1219940
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: No
Track Length: 1 829 mm
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 68 kg
