Richelieu WEBKIT1220022 Grant TopLine Low Profile Sliding Door SystemRichelieu WEBKIT1220022 Grant TopLine Low Profile Straight Sliding Door System offers a sophisticated solution for both commercial and residential applications. Designed to accommodate low profile wood doors weighing up to 500 lb (227 kg) and a minimum thickness of 1 3/8 in (35 mm), this system combines functionality with elegance. The system features precision ball bearing wheel trolleys that glide smoothly along aluminum box tracks, ensuring a seamless operation. For those looking for enhanced functionality, a Silent System soft-close and soft-open mechanism is available separately, suitable for doors weighing up to 325 lb (147 kg). This system is ideal for single, biparting, and bypassing door configurations, making it perfect for spaces with restricted headroom. Important installation notes include using the system exclusively in framed installations and ensuring that all screws are pre-drilled for optimal performance. The maximum door height supported is 9 ft 10 in, with widths ranging from 30 to 94 1/2 in. The system is designed for ceiling mounting, and it is crucial to keep tracks and guide channels clear of debris during installation. Overall, the Richelieu WEBKIT1220022 ensures a stylish and smooth sliding experience, making it a valuable addition to any space.
Grant TopLine Low Profile Straight Sliding Door System
The Grant TopLine Low Profile Straight Sliding Door System, featuring the Grant TopLine SD, Grant TopLine HD and Grant TopLine XHD, is made for low profile wood doors weighing up to 500 lb (227 kg) each and at least 1 3/8 in (35 mm) thick.
- Sleek and elegant look
- Precision ball bearing wheel trolleys run on aluminum box tracks
- Silent System soft-close and soft-open mechanism available separately for doors weighing up to 325 lb (147 kg) each.
These models are designed for commercial and residential use with single, biparting, and bypassing door applications and are ideal for restricted headroom applications.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Closet and Walk-In Closet, Cabinet, Storage
Brand: Grant Hettich
Detailed Door Movement: Single Sliding
Door Height: Max. 3 000 mm
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: Min. 35 mm
Door Width: 762 to 2 400 mm
Grant Top Line Model: Grant TopLine SD
Length - Overall Dimensions: 72 in*
Load Capacity: Max. 150 lb*
Number of Doors: 1
Overall Length: 1 829 mm
Product #: WEBKIT1220022
Product number: WEBKIT1220022
Product №: WEBKIT1220022
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: No
Track Length: 1 829 mm
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 68 kg
