Richelieu WEBKIT1220034 Grant TopLine Low Profile Sliding Door SystemRichelieu WEBKIT1220034 Grant TopLine Low Profile Straight Sliding Door System combines elegance and functionality, designed for both commercial and residential use. This system accommodates low profile wood doors with a robust capacity of up to 500 lb (227 kg) and a minimum thickness of 1 3/8 in (35 mm), ideal for spaces with restricted headroom. Featuring precision ball bearing wheel trolleys that glide smoothly on aluminum box tracks, the Grant TopLine ensures a seamless and silent operation. For added convenience, a Silent System soft-close and soft-open mechanism is available separately for doors weighing up to 325 lb (147 kg), enhancing user experience and safety. This system suits various door applications, including single, biparting, and bypassing configurations, making it versatile for closets, walk-in closets, and storage solutions. With a maximum door height of 9 ft 10 in and a width ranging from 30 to 94 1/2 in, it provides flexibility in design. Installation is straightforward, provided the opening is properly framed and leveled. However, it is crucial to follow manufacturer instructions and utilize qualified individuals for execution. Experience the perfect blend of style and practicality with the Richelieu Grant TopLine Low Profile Straight Sliding Door System.
Grant TopLine Low Profile Straight Sliding Door System
The Grant TopLine Low Profile Straight Sliding Door System, featuring the Grant TopLine SD, Grant TopLine HD and Grant TopLine XHD, is made for low profile wood doors weighing up to 500 lb (227 kg) each and at least 1 3/8 in (35 mm) thick.
- Sleek and elegant look
- Precision ball bearing wheel trolleys run on aluminum box tracks
- Silent System soft-close and soft-open mechanism available separately for doors weighing up to 325 lb (147 kg) each.
These models are designed for commercial and residential use with single, biparting, and bypassing door applications and are ideal for restricted headroom applications.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Closet and Walk-In Closet, Cabinet, Storage
Brand: Grant Hettich
Detailed Door Movement: Single Sliding
Door Height: Max. 3 000 mm
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: Min. 35 mm
Door Width: 762 to 2 400 mm
Grant Top Line Model: Grant TopLine SD
Length - Overall Dimensions: 10 ft*
Load Capacity: Max. 150 lb*
Number of Doors: 1
Overall Length: 3 048 mm
Product #: WEBKIT1220034
Product number: WEBKIT1220034
Product №: WEBKIT1220034
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: Yes
Track Length: 3 048 mm
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 68 kg
